1. The size of steel plates we can supply is 3mm-180mm * 1250mm-4000mm * 3000mm-18000mm
Size range: These are the ranges the page lists (3–180 mm × 1250–4000 mm × 3000–18000 mm). They describe the range offered, not the sizes held in stock; availability is confirmed at quotation.
2. The main standard our steel is according to ASTM A131,API.
3. The main classification society we cooperate are: ABS ,GL, LR, BV, NK,DNV,KR,RINA.
Societies: ABS is the American Bureau of Shipping, BV Bureau Veritas, GL Germanischer Lloyd, KR Korean Register, LR Lloyd’s Register, NK Nippon Kaiji Kyokai and RINA the Italian register. GL merged with DNV in 2013 and is now part of DNV, so ask which society name should appear on the certificate you need.
4. Productive technology: HR,CR,TMCP,N,Q&T,IMPACT TEST,Z15,Z25,Z35.
Abbreviations: HR is hot rolled, CR controlled rolled, TMCP thermo-mechanical controlled process, N normalised and Q&T quenched and tempered. Z15, Z25 and Z35 are through-thickness (Z-direction) quality classes.
5. Hard stamp about the brand of manufacturer, Heat No.,Batch No., steel grade, steel size, and the brand of Classification Society.
6. Blasting according to SA2.5 standard, and the shop primed on the steel, coating thickness is 15-35 micrometer.
Surface: “SA2.5” is Sa 2½, very thorough blast cleaning to ISO 8501-1. The shop primer thickness of 15–35 micrometres is the coating thickness the page lists.
Steel Plate for Ship Building & Oil Platform: Purchasing Specification
| Requirement | What to specify |
|---|---|
| Grade and society | State the steel grade (for example A, B, D, E, AH32, DH32, EH32, FH32 or AH36) and the classification society that will certify it. |
| Size | Plate thickness × width × length, or section size (for example a bulb flat, flat bar or angle designation), in mm; number of pieces or total weight. |
| Condition | Supply condition as required (as rolled, controlled rolled, TMCP or normalised) and Z-quality (Z15, Z25 or Z35) if through-thickness properties are needed. |
| Surface | Blast cleaning to Sa 2.5 and shop primer of 15–35 µm, if required, as the plate page lists. |
| Marking | Manufacturer, heat and batch number, grade, size and the classification society stamp. |
| Documents | Mill test certificate and society certificate, with impact test results where the grade requires them. |
Classification Society
| Grade | Classification Society | ||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|
| ABS | BV | DNV | GL | KR | LR | NK | RINA | ||||
| AR、CR | TMCP | N | AR、CR、N | TMCP | |||||||
| A | AB/A | AB/A | AB/AN | BVA | NV A | GL-A | GL-ATM | KRA | LRA | KA | RINA－A |
| B | AB/B | AB/B | AB/BN | BVB | NV B | GL-B | GL-BTM | KRB | LRB | KB | RINA－B |
| D | AB/D | AB/DN | AB/DN | BVD | NV D | GL-D | GL-DTM | KRD | LRD | KD | RINA－D |
| E | AB/E | AB/E | AB/EN | BVE | NV E | GL-E | GL-ETM | KRE | LRE | KE | RINA－E |
| AH32 | AB/AH32 | AB/AH32 | AB/AH32N | BVAH32 | NV A32 | GL-A32 | GL-A32TM | KRAH32 | LRAH32 | KA32 | RINA－AH32 |
| DH32 | AB/DH32 | AB/DH32N | AB/DH32N | BVDH32 | NV D32 | GL-D32 | GL-D32TM | KRDH32 | LRDH32 | KD32 | RINA－DH32 |
| EH32 | AB/EH32 | AB/EH32 | AB/EH32N | BVEH32 | NV E32 | GL-E32 | GL-E32TM | KREH32 | LREH32 | KE32 | RINA－EH32 |
| FH32 | AB/FH32 | AB/FH32 | AB/FH32N | BVFH32 | NV F32 | GL-F32 | GL-F32TM | KRFH32 | LRFH32 | KF32 | RINA－FH32 |
| AH36 | AB/AH36 | AB/AH36 | AB/AH36N | BVAH36 | NV A36 | GL-A36 | GL-A36TM | KRAH36 | LRAH36 | KA36 | RINA－AH36 |
| DH36 | AB/DH36 | AB/DH36N | AB/DH36N | BVDH36 | NV D36 | GL-D36 | GL-D36TM | KRDH36 | LRDH36 | KD36 | RINA－DH36 |
| EH36 | AB/EH36 | AB/EH36 | AB/EH36N | BVEH36 | NV E36 | GL-E36 | GL-E36TM | KREH36 | LREH36 | KE36 | RINA－EH36 |
| FH36 | AB/FH36 | AB/FH36 | AB/FH36N | BVFH36 | NV F36 | GL-F36 | GL-F36TM | KRFH36 | LRFH36 | KF36 | RINA－FH36 |
| AH40 | AB/AH40 | AB/AH40 | AB/AH40N | BVAH40 | NV A40 | GL-A40 | GL-A40TM | KRAH40 | LRAH40 | KA40 | RINA－AH40 |
| DH40 | AB/DH40 | AB/DH40N | AB/DH40N | BVDH40 | NV D40 | GL-D40 | GL-D40TM | KRDH40 | LRDH40 | KD40 | RINA－DH40 |
| EH40 | AB/EH40 | AB/EH40 | AB/EH40N | BVEH40 | NV E40 | GL-E40 | GL-E40TM | KREH40 | LREH40 | KE40 | RINA－EH40 |
| FH40 | AB/FH40 | AB/FH40 | AB/FH40N | BVFH40 | NV F40 | GL-F40 | GL-F40TM | KRFH40 | LRFH40 | KF40 | RINA－FH40 |
| AH420 | AB/AQ43 | AB/AQ43 | AB/AQ43N | BVAH420 | NV A420 | GL-A420 | GL-A420TM | KRAH43 | LRAH42 | KA43 | RINA－A420 |
| DH420 | AB/DQ43 | AB/DQ43 | AB/DQ43N | BVDH420 | NV D420 | GL-D420 | GL-D420TM | KRDH43 | LRDH42 | KD43 | RINA－D420 |
| EH420 | AB/EQ43 | AB/EQ43 | AB/EQ43N | BVEH420 | NV E420 | GL-E420 | GL-E420TM | KREH43 | LREH42 | KE43 | RINA－E420 |
| FH420 | AB/FQ43 | AB/FQ43 | AB/FQ43N | BVFH420 | NV F420 | GL-F420 | GL-F420TM | KRFH43 | LRFH42 | KF43 | RINA－F420 |
| EH460 | AB/AQ47 | AB/AQ47 | AB/AQ47N | BVAH460 | NV A460 | GL-A460 | GL-A460TM | KRAH47 | LRAH46 | KA47 | RINA－A460 |
| DH460 | AB/DQ47 | AB/DQ47 | AB/DQ47N | BVDH460 | NV D460 | GL-D460 | GL-D460TM | KRDH47 | LRDH46 | KD47 | RINA－D460 |
| EH460 | AB/EQ47 | AB/EQ47 | AB/EQ47N | BVEH460 | NV E460 | GL-E460 | GL-E460TM | KREH47 | LREH46 | KE47 | RINA－E460 |
| FH460 | AB/FQ47 | AB/FQ47 | AB/FQ47N | BVFH460 | NV F460 | GL-F460 | GL-F460TM | KRFH47 | LRFH46 | KF47 | RINA－F460 |
| API 2HCR50 | |||||||||||
Reading the table: The heading rows give the supply condition (AR/CR, TMCP or N) and each society; each row gives the society’s designation for one grade, for example grade A is “AB/A” for ABS, “BVA” for BV, “NV A” for DNV, “GL-A” for GL, “KRA” for KR, “LRA” for LR, “KA” for NK and “RINA-A” for RINA. State which designation your certificate should carry.
How the Four Ship Building Pages Differ
The four pages cover steel for ship building and oil platforms: classified plate in one page and three rolled section types, bulb flats, flat bars and angles, in the others. The plate page lists the grades by classification society; the section pages give size, weight and tolerance tables.
| Page | What it covers | Product form |
|---|---|---|
| PLATE (this page) | Plate sizes, standards and the classification society grade table | Plate, 3–180 mm thick |
| FLAT BULB | Bulb-flat size table with area, weight and allowable deviation | Section, 80 × 5 up to 430 × 20 |
| FLAT BAR | Flat-bar size table with area, weight and allowable deviation | Section, 8 × 100 up to 30 × 450 |
| ANGLE | Angle size table with section area and weight, and JIS G3192 tolerances | Section, L200 × 90 and larger |
State the grade, classification society and size on your enquiry; section sizes are listed as designations on the pages.
Related plates in this range
Applications for Steel Plate for Ship Building & Oil Platform
Typical uses include ship hulls and decks, oil platforms, and ship stiffeners and framing such as bulb flats, flat bars and angles. Tell us the load, temperature and service conditions so the right grade and thickness can be quoted.
Cutting, Fabrication and Welding
Champak Industries describes full and part plate/profile supply and a plasma-cutting service. Send drawings, quantities, tolerances and edge preparation for your parts. Shipbuilding plate and sections can be cut to size and shape to your drawings through our plasma-cutting and cutting services. Send the grade, society, size and quantity. Weld with consumables and a procedure approved by the classification society.
Testing, Inspection Documents and Traceability
| Requirement | What to identify in the order |
|---|---|
| Classification certificate | Society (ABS, BV, DNV, GL, KR, LR, NK or RINA, as the plate page lists) and certificate type |
| Mill test certificate | EN 10204 3.1 showing grade, heat number, chemistry and mechanical properties |
| Impact test | Charpy temperature and energy for the grade (A, B, D, E and the AH, DH, EH and FH grades) |
| Z-quality | Z15, Z25 or Z35 through-thickness test, if required |
| Traceability | Heat number and plate number marked on the material |
See the company’s Quality Policy for its published policy.
Source Steel Plate for Ship Building & Oil Platform from Champak Industries
Champak Industries’ company profile records its establishment in Mumbai in 1978 and its stockist, import and export activities. Steel Plate for Ship Building & Oil Platform can be requested together with other plates in the Ship Building Plates Lloyds A range.
What Determines the Quotation?
Grade and brand, thickness, plate size, quantity, cutting, testing and packing all affect the quotation. Say whether pricing is needed per kilogram, per plate or per finished piece.
Packing, Dispatch and Export Requirements
Give the delivery address, required date and unloading constraints. For export orders, include the destination port, delivery terms and document list.
Steel Plate for Ship Building & Oil Platform: Frequently Asked Questions
01What is Steel Plate for Ship Building & Oil Platform?
Steel plate for ship building and oil platforms is listed in 3–180 mm thickness to ASTM A131 and API, with approval by ABS, BV, DNV, GL, KR, LR, NK and RINA, in grades from A to FH36.
02Which sizes does the page list?
Thickness of 3–180 mm, width of 1250–4000 mm and length of 3000–18000 mm; availability of a particular size is confirmed at quotation.
03Which classification societies are listed?
ABS, BV, DNV, GL, KR, LR, NK and RINA, with the society designation of each grade in a table.
04How is the plate marked and prepared?
Hard-stamped with the manufacturer’s brand, heat and batch number, grade, size and the classification society brand; blasted to Sa 2.5 and shop primed at 15–35 micrometres.
05Can Ship building plate be welded?
Yes; shipbuilding steels are made for welded construction. Use consumables and a procedure approved by the classification society, and follow the mill’s preheat advice for the grade and thickness.
06Which certificate should I request?
A mill test certificate (EN 10204 3.1) plus the classification society certificate, showing the grade, heat number, chemistry and mechanical properties and any impact test results.
07Can another grade replace Ship building plate?
Shipbuilding grades are approved by classification societies; substitutions need the society’s agreement, so confirm any change with your surveyor or the society.
08Can Ship building plate be cut to size?
Yes. Champak Industries lists a plasma-cutting service; send drawings, quantities and tolerances with your enquiry.
09Which sizes are available?
Availability depends on the grade, society and size; send the size you need and it will be confirmed at quotation.
10How do I get a price and delivery date?
Send the grade and society, size, quantity, destination and required date through the enquiry form below, by WhatsApp or by phone.
