Hadfield manganese plates & Sheets Supplier in Mumbai-India
Hadfield Manganese Steel Plates Widely known for its work hardening properties, are amenable to high-impact wear applications or those in which scratch abrasion is encountered. These hardened steel plates enhance almost five times the hardness of mild steel and almost three times the hardness of annealed stainless steel. Due to this, one can enjoy a longer lifespan and extended protection of their equipment and facilities.
Reading the text: “Managanese” in the page title means manganese. The “five times harder than mild steel” figure refers to the work-hardened surface (about 500–550 BHN against about 120 BHN for mild steel); as delivered, at 220–250 BHN, the plate is about twice as hard as mild steel. Austenitic stainless steel is also softer than the work-hardened surface.
Hadfield Managanese Plates: Purchasing Specification
| Requirement | What to specify |
|---|---|
| Grade and standard | X120Mn12 (1.3401) or 12–14% manganese steel; say whether your drawing cites EN, DIN or the A128 Grade B-2 composition, and state the carbon and manganese range. |
| Condition | Austenitic, water-toughened (quenched) plate; it is non-magnetic and soft as delivered, and hardens only where it is worked. |
| Thickness | Properties vary with thickness; give the thickness range of your parts. |
| Cutting | Plasma, laser or waterjet cutting; oxy-fuel (flame) cutting is not suited to austenitic manganese steel. |
| Welding | Austenitic manganese consumables and low heat input; do not preheat and keep the plate cool between passes. |
| Documents | Mill test certificate (EN 10204 3.1) with chemistry and mechanical properties. |
Technical Specifications
- Tensile - 132,000 PSI
- Hardness - 250BHN
- Yield - 90,000 PSI
- Will Work Hardened to 500BHN
- Elongation - 12%
Values in the list: The list (yield 90,000 psi, tensile 132,000 psi) does not match the table below. 90,000 psi is about 620 MPa and 132,000 psi about 910 MPa, whereas the table lists yield of 350–380 MPa and tensile strength of 800–940 MPa. Use the table, and ask the mill for the guaranteed values.
Features
- High Abrasion Resistance
- Non-Magnetic Properties
- Deep Uniform Hardness
- Provide Maximum Wear Life
- Excellent Toughness
Application Used in
- Quarries and constructions
- Mines
- Iron industry and foundry
- Concrete and brick works
- Scraps
- Automotive industries
Standards
| EURONORM | 1.3401 � X120Mn13 | DIN | W1.3401 |
|---|---|---|---|
| AFNOR | X120Mn13 | ASTM | A128 Gr B2 |
Damaged characters: Some symbols were damaged on the original page and show as “�”. In this table the character between 1.3401 and X120Mn13 stands for the dash that joins the two designations. The current EN name is X120Mn12 (1.3401); X120Mn13 is an older or alternative form.
Chemical Analysis Typical values (% weight)
| C | Si | Mn | Mn | P |
|---|---|---|---|---|
| 1.13 | 0.40 | 13 | 0.003 | ≤ 0.20 |
Chemistry table: The second “Mn” heading should read S (sulphur, 0.003), and “P ≤ 0.20” looks too high: ASTM A128 allows 0.07% phosphorus maximum for this grade, so confirm the value with the mill.
Mechanical Properties
| Hardness HB | Yield Strength MPa | UTS MPa | El% | KCV 20�C (68�F) - J | |
|---|---|---|---|---|---|
| Typical Values | 220 | 380(55 KSI) | 940(136 KSI) | 40 | ≥ 112 J(≥ 83 ft.lbs) |
| Guaranteed Values* | 180/245 | 350(51 KSI) | 800(116 KSI) | 30 | 64 J(47 ft.lbs) |
Reading the properties: “KCV 20 �C (68 �F)” means the Charpy V-notch test at 20 °C (68 °F). Guaranteed values are the minimums; typical values are what the mill usually reaches.
Physical Properties
| Density * | Expansion Coeff. 0-600�C | Specific Heat | Electrical * Resistivity | Thermal * Conductivity | Magnetic * Permeability | |
|---|---|---|---|---|---|---|
| Metric US | 7.88 | 10 -6�C1 21.5 10 -60�F-1 19.9 |
J/Metric Kg. �C 502 BTU/lb�F .12 |
�O.m 75 �O.m 75 |
W/m. �C 13 BTU/hr.ft�F 7.3 |
�1.002 |
Damaged characters: The “�” in this table stands for the degree sign (°C, °F), μΩ (resistivity) and ≈ (permeability, about 1.002). The 12–14% Manganese page lists the same data with the symbols intact.
How the Four Manganese Steel Pages Differ
The four pages describe the same family of austenitic manganese steel (about 12–14% manganese and 1.1–1.3% carbon), listed under different names. The steel is soft and very tough as delivered and hardens at the surface under repeated impact, so it suits crushers and impact wear better than pure sliding abrasion.
| Page | What it covers | Typical use (from the pages) |
|---|---|---|
| 12-14% | X120Mn12 / 1.3401 steel, 11.5–14% Mn, with chemistry, mechanical and physical tables | Transport parts, grizzly bars, truck bodies |
| X120MN12 | DIN 1.3401 data sheet, 12.0–13.0% Mn, properties by thickness up to 100 mm | Crusher jaws, shovel parts, impact mills, protective plates |
| MN13 | Fully austenitic, quench-annealed, non-magnetic 12–14% manganese plate | Severe surface wear with a work-hardening effect |
| HADFIELD (this page) | The same steel under its original name: about 250 BHN, work hardening to 500 BHN | Quarries, mines, foundry, concrete and brick works, scrap, automotive |
State the carbon and manganese range and the standard on your enquiry; mills differ in detail.
Related plates in this range
Cutting, Fabrication and Welding
Champak Industries describes full and part plate/profile supply and a plasma-cutting service. Send drawings, quantities, tolerances and edge preparation for your parts. Cut by plasma, laser or waterjet (not oxy-fuel), weld with austenitic manganese consumables at low heat input, and do not preheat or heat-treat the plate after delivery without the mill’s advice.
Testing, Inspection Documents and Traceability
| Requirement | What to identify in the order |
|---|---|
| Mill test certificate | EN 10204 3.1 showing brand and grade, heat number, chemistry and mechanical properties |
| Impact test | Charpy test temperature and minimum energy, if required |
| Ultrasonic test | Standard and acceptance class, if required |
| Traceability | Heat and plate number transferred to cut pieces |
See the company’s Quality Policy for its published policy.
Source Hadfield Managanese Plates from Champak Industries
Champak Industries’ company profile records its establishment in Mumbai in 1978 and its stockist, import and export activities. Hadfield Managanese Plates can be requested together with other plates in the Manganese Steel Plates range.
What Determines the Quotation?
Grade and brand, thickness, plate size, quantity, cutting, testing and packing all affect the quotation. Say whether pricing is needed per kilogram, per plate or per finished piece.
Packing, Dispatch and Export Requirements
Give the delivery address, required date and unloading constraints. For export orders, include the destination port, delivery terms and document list.
Hadfield Managanese Plates: Frequently Asked Questions
01What is Hadfield Managanese Plates?
Hadfield manganese steel plate (ASTM A128 Grade B-2, 1.3401 X120Mn13) is an austenitic steel of about 13% manganese that is non-magnetic, tough, and work-hardens from about 220–250 BHN to 500 BHN in service.
02What is Hadfield manganese steel?
An austenitic steel with about 13% manganese and 1.1% carbon (ASTM A128 Grade B-2, 1.3401). It is tough as delivered and hardens at the surface when worked by impact or abrasion.
03What hardness values does the page list?
The table lists typical hardness of 220 HB and guaranteed 180–245 HB, and the list on the page says 250 BHN, work hardening to 500 BHN.
04Which applications are listed?
Quarries and construction, mines, the iron industry and foundry, concrete and brick works, scrap handling and the automotive industry.
05Can Hadfield manganese be welded?
Yes, with a qualified procedure and consumables suited to the grade; follow the mill’s recommendations for preheat and heat input.
06Which certificate should I request?
An EN 10204 3.1 mill test certificate showing the brand and grade, heat number, chemistry and mechanical properties, plus impact results where you specify a test temperature.
07Can another brand replace Hadfield manganese?
Brands of the same class are comparable, not identical. Chemistry, toughness, thickness range and processing advice differ by mill, so confirm any substitution with your engineer.
08Can Hadfield manganese plate be cut to size?
Yes. Champak Industries lists full and part plate and profile supply and a plasma-cutting service; send drawings, quantities and tolerances with your enquiry.
09Which sizes are available?
Availability depends on the grade, mill and thickness; send the thickness, width and length you need and sizes will be confirmed at quotation.
10How do I get a price and delivery date?
Send the grade, thickness, size or cutting drawing, quantity, destination and required date through the enquiry form below, by WhatsApp or by phone.
