Champak Industries is leading supplier of 3003 aluminium Plates and this 3003 aluminum plates react well to mechanical finishing and organic finishes as well. 3003 welding is readily accomplished by means of conventional welding methods but may be gummy if machined. Soldering is limited to the torch method. 3003 plate is generally used for manufactured stamped parts because of its light weight and moderate strength. TW has a wide range of sizes readily available to the AMS 4008 for H14.
Reading the text: “TW” is not explained; it appears to stand for the supplier. AMS 4008 is the aerospace specification for 3003 sheet and plate in H14 temper.
3003 Aluminium Plates: Purchasing Specification
| Requirement | What to specify |
|---|---|
| Alloy and temper | State both, for example 5083-H116 or 6061-T651; properties depend on the temper. |
| Standard | ASTM B209 / ASME SB209 for plate and sheet, or EN 485 / EN 573; ASTM B928 for marine-service plate in the high-magnesium alloys, as the pages cite. |
| Dimensions | Thickness × width × length in mm or inches; number of plates or total weight. |
| Cutting | Sawing or waterjet cutting to your drawing; give tolerances and edge finish. |
| Welding | Weldability depends on the alloy: the 5xxx and 6xxx alloys weld readily, while high-strength 2xxx and 7xxx alloys are generally not arc-welded. State the process. |
| Documents | Mill test certificate (EN 10204 3.1) with chemistry, temper and mechanical properties. |
Applications
- Cat Walks
- Heat Exchangers
- Food and Chemical handling equipment
- Truck and Trailer Roofing
- Floor Panels
Chemical Composition
| Chemical Element | % Present |
|---|---|
| Others (Total) | 0.0 - 0.15 |
| Cobalt (Co) | 0.05 - 0.20 |
| Hydrogen (H) | 0.0 - 0.70 |
| Magnesium (Mg) | 1.00 - 1.50 |
| Silicon + Iron (Si+Fe) | 0.0 - 0.60 |
| Zirconium (Zr) | 0.0 - 0.10 |
| Other (Each) | 0.0 - 0.05 |
| Aluminium (Al) | Balance |
Composition table: This is not the standard 3003 composition. Alloy 3003 is aluminium with about 1.0–1.5% manganese, but the table lists “Magnesium 1.00–1.50” where manganese is meant and also shows cobalt, hydrogen and zirconium, which are not 3003 limits. Ask the mill for the 3003 chemistry on the certificate.
Properties
| Physical Property | Value |
|---|---|
| Density | 2.73 g/cm³ |
| Melting Point | 655 °C |
| Thermal Expansion | 23.1 x10^-6 /K |
| Modulus of Elasticity | 69.5 GPa |
| Thermal Conductivity | 190 W/m.K |
| Electrical Resistivity | 0.034 x10^-6 Ω .m |
| Spec: BS EN 485-2:2008 | Sheet - 0.2mm to 6.00mm |
|---|---|
| Mechanical Property | Value |
| Tensile Strength | 95 - 135 MPa |
| Proof Stress | 35 Min MPa |
| Hardness Brinell | 28 HB |
Reading the table: This table holds the mechanical values, for sheet of 0.2–6.00 mm to BS EN 485-2:2008, under the heading “Properties”; the table above it holds the physical values.
How the Eighteen Aluminium Alloys Differ
The eighteen pages cover aluminium alloys from several families. The 1xxx, 3xxx and 5xxx alloys are non-heat-treatable and gain strength by cold work, while the 2xxx, 6xxx and 7xxx alloys are heat-treatable. The 5xxx magnesium alloys are the usual marine and welded-structure choice; the 2xxx and 7xxx alloys are the high-strength aerospace alloys.
| Alloy | Family and hardening | Typical use (from the pages) |
|---|---|---|
| 1050A | 1xxx pure aluminium (99.5%), non-heat-treatable | General sheet-metal work, packaging, heat transfer, kitchenware |
| 1350 | 1xxx electrical-grade aluminium (99.5% min), non-heat-treatable | Transformer and switchgear conductors |
| 2024 | 2xxx aluminium-copper, heat-treatable | Aircraft structure, precision fittings, truck wheels |
| 2124 | 2xxx aluminium-copper, high-purity 2024, heat-treatable | Machined fuselage bulkheads, military aircraft wing skins |
| 2219 | 2xxx aluminium-copper, heat-treatable | Space boosters, fuel tanks, high-temperature structures |
| 3003 (this page) | 3xxx aluminium-manganese, non-heat-treatable | Heat exchangers, catwalks, food and chemical equipment, roofing |
| 5052 | 5xxx aluminium-magnesium, non-heat-treatable | Fuel tanks, truck panels, small boat hulls, pressure vessels |
| 5083 | 5xxx aluminium-magnesium (4.0–4.9% Mg) | LNG ships, pressure vessels, storage tanks, welded structures |
| 5086 | 5xxx aluminium-magnesium (3.5–4.5% Mg) | Shipyard work, tank cars, patrol and work-boat hulls |
| 5154 | 5xxx aluminium-magnesium (3.1–3.9% Mg) | Wire, rivets and cold-heading applications |
| 5454 | 5xxx aluminium-magnesium (2.4–3.0% Mg) | Road transport, chemical plant, pressure vessels, marine and off-shore |
| 5456 | 5xxx aluminium-magnesium (about 5% Mg) | Welded structures, low-temperature service |
| 5754 | 5xxx aluminium-magnesium (2.6–3.6% Mg) | Treadplate, shipbuilding, vehicle bodies, food processing |
| 6061-T6 | 6xxx aluminium-magnesium-silicon, heat-treatable | Tooling plate, architectural, transport, welded structures |
| 7050 | 7xxx aluminium-zinc-magnesium-copper, heat-treatable | Aerospace fuselage frames and bulkheads |
| 7075 | 7xxx aluminium-zinc, heat-treatable | Airframe structures and highly stressed parts |
| 7175 | 7xxx aluminium-zinc, heat-treatable forging alloy | Structural fittings, bolts and rivets |
| 7475 | 7xxx aluminium-zinc, controlled toughness, heat-treatable | Wing spars and fuselage bulkheads |
State the alloy, temper and standard on your enquiry. Families are summarised for orientation; the mill certificate gives the actual chemistry and properties.
Related plates in this range
- 1050A Aluminium Plates
- 1350 Aluminium Plates
- 2024 Aluminium Plates
- 2124 Aluminium Plates
- 2219 Aluminium Plates
- 5052 Aluminium Plates
- 5083 Aluminium Plates
- 5086 Aluminium Plates
- 5154 Aluminium Plates
- 5454 Aluminium Plates
- 5456 Aluminium Plates
- 5754 Aluminium Plates
- 6061 T6 Aluminium Plates
- 7050 Aluminium Plates
- 7075 Aluminium Plates
- 7175 Aluminium Plates
- 7475 Aluminium Plates
Cutting, Fabrication and Welding
Champak Industries describes full and part plate/profile supply and a plasma-cutting service. Send drawings, quantities, tolerances and edge preparation for your parts. Aluminium plate can be sawn, waterjet cut or machined to your drawing. Weldability depends on the alloy: the 5xxx and 6xxx alloys weld readily with a suitable filler, while the high-strength 2xxx and 7xxx alloys are generally not arc-welded. Send the alloy, temper and drawing with your enquiry.
Testing, Inspection Documents and Traceability
| Requirement | What to identify in the order |
|---|---|
| Mill test certificate | EN 10204 3.1 showing alloy, temper, lot number, chemistry and mechanical properties |
| Temper | Alloy and temper marked on the plate and the certificate (for example H116 or T651) |
| Ultrasonic test | Standard and acceptance class for thick plate, if required |
| Traceability | Lot or plate number transferred to cut pieces |
See the company’s Quality Policy for its published policy.
Source 3003 Aluminium Plates from Champak Industries
Champak Industries’ company profile records its establishment in Mumbai in 1978 and its stockist, import and export activities. 3003 Aluminium Plates can be requested together with other plates in the Aluminium Plates range.
What Determines the Quotation?
Grade and brand, thickness, plate size, quantity, cutting, testing and packing all affect the quotation. Say whether pricing is needed per kilogram, per plate or per finished piece.
Packing, Dispatch and Export Requirements
Give the delivery address, required date and unloading constraints. For export orders, include the destination port, delivery terms and document list.
3003 Aluminium Plates: Frequently Asked Questions
01What is 3003 Aluminium Plates?
3003 is a non-heat-treatable aluminium-manganese alloy of moderate strength and light weight that welds readily and takes mechanical and organic finishes, used for stamped parts, heat exchangers and floor panels.
02What is 3003 aluminium used for?
Cat walks, heat exchangers, food and chemical handling equipment, truck and trailer roofing and floor panels, and stamped parts.
03How does 3003 weld and machine?
Welding is readily done with conventional methods, but the alloy may be gummy when machined; soldering is limited to the torch method.
04What mechanical values does the page list?
For sheet of 0.2–6.00 mm to BS EN 485-2:2008: tensile strength of 95–135 MPa, proof stress of 35 MPa minimum and 28 HB hardness.
05Can 3003 be welded?
It depends on the alloy and temper. The 5xxx and 6xxx alloys weld readily with a suitable filler; high-strength 2xxx and 7xxx alloys are generally not arc-welded. Ask for welding advice for your alloy.
06Which certificate should I request?
An EN 10204 3.1 mill test certificate showing the alloy and temper, lot number, chemistry and mechanical properties.
07Can another alloy replace 3003?
Alloys of the same family are comparable, not identical. Strength, corrosion resistance, weldability and formability differ, so confirm any substitution with your engineer.
08Can 3003 plate be cut to size?
Yes. Plate can be sawn or waterjet cut to your drawing; send the drawing, quantities and tolerances with your enquiry.
09Which sizes are available?
Availability depends on the alloy, temper and thickness; send the thickness, width and length you need and sizes will be confirmed at quotation.
10How do I get a price and delivery date?
Send the alloy and temper, thickness, size or cutting drawing, quantity, destination and required date through the enquiry form below, by WhatsApp or by phone.
