We have huge stock of 5754 aluminium/ Aluminum plates. Aluminium 5754 has excellent corrosion resistance especially to seawater and industrially polluted atmospheres and it has high weldability . It has higher strength than 5251. This high strength makes 5754 highly suited to flooring applications.
5754 Aluminium Plates: Purchasing Specification
| Requirement | What to specify |
|---|---|
| Alloy and temper | State both, for example 5083-H116 or 6061-T651; properties depend on the temper. |
| Standard | ASTM B209 / ASME SB209 for plate and sheet, or EN 485 / EN 573; ASTM B928 for marine-service plate in the high-magnesium alloys, as the pages cite. |
| Dimensions | Thickness × width × length in mm or inches; number of plates or total weight. |
| Cutting | Sawing or waterjet cutting to your drawing; give tolerances and edge finish. |
| Welding | Weldability depends on the alloy: the 5xxx and 6xxx alloys weld readily, while high-strength 2xxx and 7xxx alloys are generally not arc-welded. State the process. |
| Documents | Mill test certificate (EN 10204 3.1) with chemistry, temper and mechanical properties. |
Applications
- . Treadplate
- . Shipbuilding
- . Vehicle bodies
- . Rivets
- . Fishing industry equipment
- . Food processing
- . Welded chemical and nuclear structures
Chemical Composition
| Chemical Element | % Present |
|---|---|
| Manganese (Mn) | 0.0 - 0.50 |
| Iron (Fe) | 0.0 - 0.40 |
| Magnesium (Mg) | 2.60 - 3.60 |
| Silicon (Si) | 0.0 - 0.40 |
| Chromium (Cr) | 0.0 - 0.30 |
| Copper (Cu) | 0.0 - 0.10 |
| Manganese + Chromium (Mn+Cr) | 0.10 - 0.60 |
| Other (Each) | 0.0 - 0.05 |
| Others (Total) | 0.0 - 0.15 |
| Titanium (Ti) | 0.0 - 0.15 |
| Zinc (Zn) | 0.0 - 0.20 |
| Aluminium (Al) | Balance |
Reading the table: Values are maximum percentages unless a range is given; the combined Mn + Cr limit is 0.10–0.60%.
Physical Properties
| Physical Property | Value |
|---|---|
| Density | 2.66 g/cm³ |
| Melting Point | 600 °C |
| Thermal Expansion | 24 x10^-6 /K |
| Modulus of Elasticity | 68 GPa |
| Thermal Conductivity | 147 W/m.K |
| Electrical Resistivity | 0.049 x10^-6 Ω .m |
| Spec: BS EN 485-2:2008 | Sheet & Plate - 0.2mm to 40mm |
|---|---|
| Mechanical Property | Value |
| Proof Stress | 130 Min MPa |
| Tensile Strength | 220 - 270 MPa |
| Hardness Brinell | 63 HB |
| Elongation A50 mm | 7 Min % |
Heading: The tables under “Physical Properties” are physical (density, melting point, conductivity) and mechanical (proof stress, tensile strength, hardness and elongation) values. This second table is the mechanical one.
How the Eighteen Aluminium Alloys Differ
The eighteen pages cover aluminium alloys from several families. The 1xxx, 3xxx and 5xxx alloys are non-heat-treatable and gain strength by cold work, while the 2xxx, 6xxx and 7xxx alloys are heat-treatable. The 5xxx magnesium alloys are the usual marine and welded-structure choice; the 2xxx and 7xxx alloys are the high-strength aerospace alloys.
| Alloy | Family and hardening | Typical use (from the pages) |
|---|---|---|
| 1050A | 1xxx pure aluminium (99.5%), non-heat-treatable | General sheet-metal work, packaging, heat transfer, kitchenware |
| 1350 | 1xxx electrical-grade aluminium (99.5% min), non-heat-treatable | Transformer and switchgear conductors |
| 2024 | 2xxx aluminium-copper, heat-treatable | Aircraft structure, precision fittings, truck wheels |
| 2124 | 2xxx aluminium-copper, high-purity 2024, heat-treatable | Machined fuselage bulkheads, military aircraft wing skins |
| 2219 | 2xxx aluminium-copper, heat-treatable | Space boosters, fuel tanks, high-temperature structures |
| 3003 | 3xxx aluminium-manganese, non-heat-treatable | Heat exchangers, catwalks, food and chemical equipment, roofing |
| 5052 | 5xxx aluminium-magnesium, non-heat-treatable | Fuel tanks, truck panels, small boat hulls, pressure vessels |
| 5083 | 5xxx aluminium-magnesium (4.0–4.9% Mg) | LNG ships, pressure vessels, storage tanks, welded structures |
| 5086 | 5xxx aluminium-magnesium (3.5–4.5% Mg) | Shipyard work, tank cars, patrol and work-boat hulls |
| 5154 | 5xxx aluminium-magnesium (3.1–3.9% Mg) | Wire, rivets and cold-heading applications |
| 5454 | 5xxx aluminium-magnesium (2.4–3.0% Mg) | Road transport, chemical plant, pressure vessels, marine and off-shore |
| 5456 | 5xxx aluminium-magnesium (about 5% Mg) | Welded structures, low-temperature service |
| 5754 (this page) | 5xxx aluminium-magnesium (2.6–3.6% Mg) | Treadplate, shipbuilding, vehicle bodies, food processing |
| 6061-T6 | 6xxx aluminium-magnesium-silicon, heat-treatable | Tooling plate, architectural, transport, welded structures |
| 7050 | 7xxx aluminium-zinc-magnesium-copper, heat-treatable | Aerospace fuselage frames and bulkheads |
| 7075 | 7xxx aluminium-zinc, heat-treatable | Airframe structures and highly stressed parts |
| 7175 | 7xxx aluminium-zinc, heat-treatable forging alloy | Structural fittings, bolts and rivets |
| 7475 | 7xxx aluminium-zinc, controlled toughness, heat-treatable | Wing spars and fuselage bulkheads |
State the alloy, temper and standard on your enquiry. Families are summarised for orientation; the mill certificate gives the actual chemistry and properties.
Related plates in this range
- 1050A Aluminium Plates
- 1350 Aluminium Plates
- 2024 Aluminium Plates
- 2124 Aluminium Plates
- 2219 Aluminium Plates
- 3003 Aluminium Plates
- 5052 Aluminium Plates
- 5083 Aluminium Plates
- 5086 Aluminium Plates
- 5154 Aluminium Plates
- 5454 Aluminium Plates
- 5456 Aluminium Plates
- 6061 T6 Aluminium Plates
- 7050 Aluminium Plates
- 7075 Aluminium Plates
- 7175 Aluminium Plates
- 7475 Aluminium Plates
Cutting, Fabrication and Welding
Champak Industries describes full and part plate/profile supply and a plasma-cutting service. Send drawings, quantities, tolerances and edge preparation for your parts. Aluminium plate can be sawn, waterjet cut or machined to your drawing. Weldability depends on the alloy: the 5xxx and 6xxx alloys weld readily with a suitable filler, while the high-strength 2xxx and 7xxx alloys are generally not arc-welded. Send the alloy, temper and drawing with your enquiry.
Testing, Inspection Documents and Traceability
| Requirement | What to identify in the order |
|---|---|
| Mill test certificate | EN 10204 3.1 showing alloy, temper, lot number, chemistry and mechanical properties |
| Temper | Alloy and temper marked on the plate and the certificate (for example H116 or T651) |
| Ultrasonic test | Standard and acceptance class for thick plate, if required |
| Traceability | Lot or plate number transferred to cut pieces |
See the company’s Quality Policy for its published policy.
Source 5754 Aluminium Plates from Champak Industries
Champak Industries’ company profile records its establishment in Mumbai in 1978 and its stockist, import and export activities. 5754 Aluminium Plates can be requested together with other plates in the Aluminium Plates range.
What Determines the Quotation?
Grade and brand, thickness, plate size, quantity, cutting, testing and packing all affect the quotation. Say whether pricing is needed per kilogram, per plate or per finished piece.
Packing, Dispatch and Export Requirements
Give the delivery address, required date and unloading constraints. For export orders, include the destination port, delivery terms and document list.
5754 Aluminium Plates: Frequently Asked Questions
01What is 5754 Aluminium Plates?
5754 is a non-heat-treatable aluminium-magnesium alloy (2.6–3.6% Mg) with excellent resistance to seawater and industrially polluted atmospheres and high weldability, used for treadplate, shipbuilding and vehicle bodies.
02Which applications are listed?
Treadplate, shipbuilding, vehicle bodies, rivets, fishing-industry equipment, food processing, and welded chemical and nuclear structures.
03Which mechanical values does the page list?
For sheet and plate of 0.2–40 mm to BS EN 485-2:2008: proof stress 130 MPa minimum, tensile strength 220–270 MPa, 63 HB and elongation (A50) of 7% minimum.
04How does 5754 compare with 5251?
The page says 5754 has higher strength than 5251, which makes it suitable for flooring applications.
05Can 5754 be welded?
It depends on the alloy and temper. The 5xxx and 6xxx alloys weld readily with a suitable filler; high-strength 2xxx and 7xxx alloys are generally not arc-welded. Ask for welding advice for your alloy.
06Which certificate should I request?
An EN 10204 3.1 mill test certificate showing the alloy and temper, lot number, chemistry and mechanical properties.
07Can another alloy replace 5754?
Alloys of the same family are comparable, not identical. Strength, corrosion resistance, weldability and formability differ, so confirm any substitution with your engineer.
08Can 5754 plate be cut to size?
Yes. Plate can be sawn or waterjet cut to your drawing; send the drawing, quantities and tolerances with your enquiry.
09Which sizes are available?
Availability depends on the alloy, temper and thickness; send the thickness, width and length you need and sizes will be confirmed at quotation.
10How do I get a price and delivery date?
Send the alloy and temper, thickness, size or cutting drawing, quantity, destination and required date through the enquiry form below, by WhatsApp or by phone.
