Champak Industries is Specialist in the supply and fabrication of ABRAZO 450 plates or wear resistant plates and high strength, quenched and tempered steels, primarily for heavy industries including Mining, Recycling Equipment, Lifting and Agricultural Equipment manufacturers.
- Longer life.
- Lower costs per tonne processed.
- Less weight.
- Excellent welding properties.
Steel pro's staff have decades of experience, offering extensive product knowledge and advice. Together with a range of dedicated machine tools, products of the highest quality and lowest prices are achieved.
Text from another company: “Steel pro’s staff” refers to another company; this paragraph was copied from its website. The longer life, lower cost and weight benefits listed above are general mill guidance, not guarantees.
Hardox® 400 / Hardox® 450 / Hardox® 500 plates
Hardox® 400 Hardness 400HB / Hardox® 450 Hardness 450HB Wear Abrasion Resistant Steel Plates
Hardox®® 400 Wear Abrasion Resistant Steel Plates - Available ex-stock
Hardox®® 450 Wear Abrasion Resistant Steel Plates - Available ex-stock
Hardox®® 500 Wear Abrasion Resistant Steel Plates - Available ex-stock
Hardox®® 600 Wear Abrasion Resistant Steel Plates - Available ex-stock
RAEX 400 Wear Abrasion Resistant Steel Plates - Available ex-stock
RAEX 450 Wear Abrasion Resistant Steel Plates - Available ex-stock
RAEX 500 Wear Abrasion Resistant Steel Plates - Available ex-stock
FORA 400 Wear Abrasion Resistant Steel Plates - Available ex-stock
FORA 450 Wear Abrasion Resistant Steel Plates - Available ex-stock
FORA 500 Wear Abrasion Resistant Steel Plates - Available ex-stock
CREUSABRO 4000 Wear Abrasion Resistant Steel Plates - Available ex-stock
CREUSABRO 4800 Wear Abrasion Resistant Steel Plates - Available ex-stock
CREUSABRO 8000 Wear Abrasion Resistant Steel Plates - Available ex-stock
CREUSABRO M (Hadfield) Wear Abrasion Resistant Steel Plates - Available ex-stock
ABRAZO 400 Wear Abrasion Resistant Steel Plates - Available ex-stock
ABRAZO 450 Wear Abrasion Resistant Steel Plates - Available ex-stock
ABRAZO 500 Wear Abrasion Resistant Steel Plates - Available ex-stock
NICRODUR 400 Wear Abrasion Resistant Steel Plates - Available ex-stock
NICRODUR 450 Wear Abrasion Resistant Steel Plates - Available ex-stock
NICRODUR 500 Wear Abrasion Resistant Steel Plates - Available ex-stock
BRINAR 400 Wear Abrasion Resistant Steel Plates - Available ex-stock
BRINAR 450 Wear Abrasion Resistant Steel Plates - Available ex-stock
BRINAR 500 Wear Abrasion Resistant Steel Plates - Available ex-stock
DUROSTAT 400 Wear Abrasion Resistant Steel Plates - Available ex-stock
DUROSTAT 450 Wear Abrasion Resistant Steel Plates - Available ex-stock
DUROSTAT 500 Wear Abrasion Resistant Steel Plates - Available ex-stock
DILLIDUR 400V Wear Abrasion Resistant Steel Plates - Available ex-stock
DILLIDUR 450V Wear Abrasion Resistant Steel Plates - Available ex-stock
DILLIDUR 500V Wear Abrasion Resistant Steel Plates - Available ex-stock
JFE EVERHARD EH360 Wear Abrasion Resistant Steel Plates - Available ex-stock
JFE EVERHARD EH360LE Wear Abrasion Resistant Steel Plates - Available ex-stock
JFE EVERHARD EH400 Wear Abrasion Resistant Steel Plates - Available ex-stock
JFE EVERHARD EH500 Wear Abrasion Resistant Steel Plates - Available ex-stock
JFE EVERHARD EH500LE Wear Abrasion Resistant Steel Plates - Available ex-stock
SUMIHARD K340 Wear Abrasion Resistant Steel Plates - Available ex-stock
SUMIHARD K400 Wear Abrasion Resistant Steel Plates - Available ex-stock
SUMIHARD K500 Wear Abrasion Resistant Steel Plates - Available ex-stock
400HB Hardness Wear Abrasion Resistant Steel Plates - Available ex-stock
450HB Hardness Wear Abrasion Resistant Steel Plates - Available ex-stock
500HB Hardness Wear Abrasion Resistant Steel Plates - Available ex-stock
400 BHN Hardness Wear Abrasion Resistant Steel Plates - Available ex-stock
450 BHN Hardness Wear Abrasion Resistant Steel Plates - Available ex-stock
500 BHN Hardness Wear Abrasion Resistant Steel Plates - Available ex-stock
XAR 400 Wear Abrasion Resistant Steel Plates - Available ex-stock
XAR 450 Wear Abrasion Resistant Steel Plates - Available ex-stock
XAR 500 Wear Abrasion Resistant Steel Plates - Available ex-stock
About this list: These brands are listed in the original as available ex-stock; confirm current availability, mill and thickness with your enquiry. Hardox is a trade mark of SSAB. CREUSABRO M (Hadfield) is an austenitic manganese steel, not a quenched and tempered wear plate; see Manganese Steel Plates.
We mainly stock the Plates of following make:
- Sumitomo Metal - Japan
- JFE Steel - Japan
- Kobe Steel - Japan
- Japan Steel - Japan
- Nippon Steel - Japan
- Salzgitter Mannesmann - Germany
- ThyssenKrupp Steel - Germany
- ThyssenKrupp Stahl - Germany
- Dillinger Hutte - Germany
- Rautaruukki - Finland
- Voestalphine Grobblech - Austria
- Corus - U.K
- InduSteel - France
- InduSteel - Belgium
- SSAB - Sweden
Mill names: Several names have changed: Sumitomo Metal is now part of Nippon Steel, Rautaruukki is now part of SSAB, Corus is now Tata Steel and ThyssenKrupp Steel is now thyssenkrupp Steel Europe. “Voestalphine” means voestalpine.
Abrazo 450 Plates: Purchasing Specification
| Requirement | What to specify |
|---|---|
| Brand and grade | Abrazo 450 Plates; state whether another brand of the 450 HBW class is acceptable. |
| Hardness | 450 HB nominal on this page; confirm the guaranteed range for your thickness. |
| Dimensions | Thickness × width × length and the number of plates, or a cutting drawing. Sizes are confirmed at quotation. |
| Toughness | Charpy impact test temperature and minimum energy, where the part sees impact or cold service. |
| Processing | Cut-to-size parts, bending and edge preparation, with drawings and tolerances. |
| Documents | EN 10204 3.1 mill test certificate with chemistry and hardness. |
Inspection & Approval Certificates
EN10204 3.1 / DIN 50049 3.1 / ISO 10474 3.1 Mill Test Certificate, NACE MR-0175 / ISO 15156, NACE MR-01-03 / NACE MR-01-75 / ISO 15156, CE Marked, European Pressure Equipment Directive PED-97/23/EC, AD-2000-W0, ASME Boiler & Pressure Vessel Code Sec.II Part A Ed. 2008, with 3.2 certificate duly Certified & Approved by LRS (Lloyd's Register), GL (Germanischer Lloyd), BV (Bureau Veritas), DNV (Det Norske Veritas), ABS (American Bureau of Shipping), SGS, TUV, RINA, IRS, NORSOK Approved Standard M-630, M-650 Rev.3
Certificates for wear plate: Wear plate is not pressure-equipment or sour-service material, so NACE, PED, AD 2000, ASME and NORSOK approvals do not normally apply to it. For wear plate, request an EN 10204 3.1 mill test certificate and name any third-party inspection agency you need.
Choosing Abrazo 450 Plates
Abrazo 450 Plates is in the 450 HBW hardness class. Higher hardness generally lasts longer against sliding abrasion but is harder to bend, cut and weld; where parts also take heavy impact, a tougher, lower class can last longer.
| Class | Nominal hardness | Typical use | Forming and welding |
|---|---|---|---|
| 400 | About 400 HBW | Dumper bodies, chutes, hoppers, screens | Cold bending and welding with normal care |
| 450 (this page) | About 450 HBW | Buckets, liners and heavier wear parts | Larger bending radii; preheat thicker sections |
| 500 | About 500 HBW | Cutting edges, crusher and severe-abrasion liners | Limited forming; strict cutting and welding procedures |
Other Abrazo classes
Brands of the same class are comparable, not identical; confirm any substitution with the end user. See all brands on Wear Resistant Plates.
Applications for Abrazo 450 Plates
Typical uses include tipper bodies, cutting edges, crushing machinery and excavator buckets. Tell us the abrasive material, impact level and the life of the current part so the right class can be quoted.
Cutting, Fabrication and Welding
Champak Industries describes full and part plate/profile supply and a plasma-cutting service. Thermal cutting softens a narrow edge zone, and thick or hard plate may need preheat before cutting. Weld with low-hydrogen consumables and the mill’s preheat and interpass limits; do not heat the plate above the mill’s tempering limit. See AR Plates for bending and drilling guidance.
Testing, Inspection Documents and Traceability
| Requirement | What to identify in the order |
|---|---|
| Mill test certificate | EN 10204 3.1 showing brand and grade, heat number, chemistry and hardness |
| Impact test | Charpy test temperature and minimum energy, if required |
| Traceability | Heat and plate number transferred to cut pieces |
See the company’s Quality Policy for its published policy.
Source Abrazo 450 Plates from Champak Industries
Champak Industries’ company profile records its establishment in Mumbai in 1978 and its stockist, import and export activities. Abrazo 450 Plates can be requested together with other brands in the Wear Resistant Plates range.
What Determines the Quotation?
Brand, hardness class, thickness, plate size, quantity, cutting, testing and packing all affect the quotation. Say whether pricing is needed per kilogram, per plate or per finished piece.
Packing, Dispatch and Export Requirements
Give the delivery address, required date and unloading constraints. For export orders, include the destination port, delivery terms and document list.
Abrazo 450 Plates: Frequently Asked Questions
01What is Abrazo 450 Plates?
Abrazo 450 Plates is wear-resistant steel plate in the 450 Brinell hardness class, made by Tata Steel. It is used where abrasion shortens the life of ordinary structural steel.
02What hardness does Abrazo 450 Plates have?
This page gives 450 HB nominal. Hardness ranges can fall with thickness, so confirm the guaranteed range for your thickness on the mill’s datasheet.
03Who makes this plate?
Abrazo plate is made by Tata Steel. The mill and heat number are shown on the mill test certificate.
04Which thicknesses are listed?
This page does not list a thickness range; send the thickness you need and availability will be confirmed at quotation.
05Is Abrazo 450 Plates the same as other 450 HBW wear plates?
Wear plates of the same hardness class are comparable, not identical. Chemistry, toughness and processing advice differ by mill, so confirm any substitution with the end user.
06Can Abrazo 450 Plates be bent?
Yes, by cold bending with larger punch radii and die openings than mild steel. Follow the mill’s minimum radius for the thickness and rolling direction.
07Can Abrazo 450 Plates be welded?
Yes, with low-hydrogen consumables and the preheat and interpass temperatures the mill gives for the grade and combined thickness.
08What is Abrazo 450 Plates used for?
Typical uses on this page include tipper bodies, cutting edges, crushing machinery and excavator buckets.
09Which certificate should I request?
An EN 10204 3.1 mill test certificate showing the brand and grade, heat number, chemistry and hardness, plus impact results where you specify a test temperature.
10How do I get a price and delivery date?
Send the brand and grade, thickness, size or cutting drawing, quantity, destination and required date through the enquiry form below, by WhatsApp or by phone.
