Champak Industries offer our clients with a qualitative range of ABRAZO 500 plates and Hardox® Plates. These wear resistance plates, which have extra high toughness intended for heavy section, wear parts for extraordinary crack resistance. Our range is manufactured in accordance with the set industry standards and offers excellent performance in its usage. These are also customized to meet the specific requirements of our esteemed clients and offered at competitive prices.
Reading the description: There is no single industry standard for wear plate; each brand follows its mill’s datasheet. “Brinel” means Brinell.
Steels with a high HB rating (Brinel Hardness) are intended for applications where wear or abrasion resistance is important. The benefit of using an abrasion resistant steel is that that the plant, machinery or constructions working life can be extended considerably. This can significantly improve the reliability, durability and safety of structures and equipment. It also helps to reduce the maintenance costs associated with wear and breakdown of plant.
GRADES : Hardox® 400 / Hardox® 450 / Hardox® 500 / JFE 360 LE / SR 400 / SR 450 / SR 500 / SUMI-HARD 400 / SUMI-HARD 500.
Abrazo 500 Plates: Purchasing Specification
| Requirement | What to specify |
|---|---|
| Brand and grade | Abrazo 500 Plates; state whether another brand of the 500 HBW class is acceptable. |
| Hardness | 500 HB nominal on this page; confirm the guaranteed range for your thickness. |
| Dimensions | Thickness × width × length and the number of plates, or a cutting drawing. Sizes are confirmed at quotation. |
| Toughness | Charpy impact test temperature and minimum energy, where the part sees impact or cold service. |
| Processing | Cut-to-size parts, bending and edge preparation, with drawings and tolerances. |
| Documents | EN 10204 3.1 mill test certificate with chemistry and hardness. |
Our range of Hardox® plates is in great demand because of its following features
- Durability
- Abrasion resistance
- Sturdy construction
- High tensile strength
- Excellent finish
Materials
- Durability
- Hardox® 400 Steel Plates
- Hardox® 450 Steel Plates
- Hardox® 500 Steel Plates
- Hardox® OX 600 Steel Plates Abrasion Resistant Plates
- Wear Resistant Plates
- Sailhard Wear Abrasion Resistant Steel Plates
- LAS07/LSLAS07 Steel Plates
- RAEX 400 Steel Plates
- RAEX 450 Steel Plates
- RAEX 500 Steel Plates
- FORA 400 Steel Plates
- FORA 450 Steel Plates
- FORA 500 Steel Plates
- Creusabro 4000 Steel Plates
- Creusabro 4800 Steel Plates
- Creusabro 8000 Steel Plates
- Hadfield High Manganese Plates
- Abrazo 400 Steel Plates
- Abrazo 450 Steel Plates
- Abrazo 500 Steel Plates
- Nicrodur 400 Steel Plates
- Nicrodur 450 Steel Plates
- Nicrodur 500 Steel Plates
- Dillidur 400V Steel Plates
- Dillidur 450V Steel Plates
- Dillidur 500V Steel Plates
- JFE Everhard EH360 Steel Plates
- JFE Everhard EH360LE Steel Plates
- JFE Everhard EH400 Steel Plates
- JFE Everhard EH500 Steel Plates
- JFE Everhard EH500LE Steel Plates
- Sumihard K340 Steel Plates
- Sumihard K400 Steel Plates
- Sumihard K500 Steel Plates
- Hardox® Extreme
- Hardox® Hituf
- Domex
- Domex 460 MC
- Domex 700MC
- DOMEX WEAR 400
- Weldox
- Weldox 700
- Weldox 900
- Weldox 960
- Weldox 1100
- Weldox 1300
- QUARD
- Quard 400
- Quard 500
- Dillimax 690
- Naxtra 700
- OPTIM700
- JFE 780LE
About this list: The list mixes wear plates with other steels. Domex, Weldox, Dillimax, Naxtra, OPTIM 700 and JFE 780LE are high-strength structural steels, see High Tensile Plates; Hadfield is an austenitic manganese steel, see Manganese Steel Plates. “Durability” at the top of the list is a feature, not a material. Hardox is a trade mark of SSAB.
Choosing Abrazo 500 Plates
Abrazo 500 Plates is in the 500 HBW hardness class. Higher hardness generally lasts longer against sliding abrasion but is harder to bend, cut and weld; where parts also take heavy impact, a tougher, lower class can last longer.
| Class | Nominal hardness | Typical use | Forming and welding |
|---|---|---|---|
| 400 | About 400 HBW | Dumper bodies, chutes, hoppers, screens | Cold bending and welding with normal care |
| 450 | About 450 HBW | Buckets, liners and heavier wear parts | Larger bending radii; preheat thicker sections |
| 500 (this page) | About 500 HBW | Cutting edges, crusher and severe-abrasion liners | Limited forming; strict cutting and welding procedures |
Other Abrazo classes
Brands of the same class are comparable, not identical; confirm any substitution with the end user. See all brands on Wear Resistant Plates.
Applications for Abrazo 500 Plates
Typical uses include tipper bodies, cutting edges, crushing machinery and excavator buckets. Tell us the abrasive material, impact level and the life of the current part so the right class can be quoted.
Cutting, Fabrication and Welding
Champak Industries describes full and part plate/profile supply and a plasma-cutting service. Thermal cutting softens a narrow edge zone, and thick or hard plate may need preheat before cutting. Weld with low-hydrogen consumables and the mill’s preheat and interpass limits; do not heat the plate above the mill’s tempering limit. See AR Plates for bending and drilling guidance.
Testing, Inspection Documents and Traceability
| Requirement | What to identify in the order |
|---|---|
| Mill test certificate | EN 10204 3.1 showing brand and grade, heat number, chemistry and hardness |
| Impact test | Charpy test temperature and minimum energy, if required |
| Traceability | Heat and plate number transferred to cut pieces |
See the company’s Quality Policy for its published policy.
Source Abrazo 500 Plates from Champak Industries
Champak Industries’ company profile records its establishment in Mumbai in 1978 and its stockist, import and export activities. Abrazo 500 Plates can be requested together with other brands in the Wear Resistant Plates range.
What Determines the Quotation?
Brand, hardness class, thickness, plate size, quantity, cutting, testing and packing all affect the quotation. Say whether pricing is needed per kilogram, per plate or per finished piece.
Packing, Dispatch and Export Requirements
Give the delivery address, required date and unloading constraints. For export orders, include the destination port, delivery terms and document list.
Abrazo 500 Plates: Frequently Asked Questions
01What is Abrazo 500 Plates?
Abrazo 500 Plates is wear-resistant steel plate in the 500 Brinell hardness class, made by Tata Steel. It is used where abrasion shortens the life of ordinary structural steel.
02What hardness does Abrazo 500 Plates have?
This page gives 500 HB nominal. Hardness ranges can fall with thickness, so confirm the guaranteed range for your thickness on the mill’s datasheet.
03Who makes this plate?
Abrazo plate is made by Tata Steel. The mill and heat number are shown on the mill test certificate.
04Which thicknesses are listed?
This page does not list a thickness range; send the thickness you need and availability will be confirmed at quotation.
05Is Abrazo 500 Plates the same as other 500 HBW wear plates?
Wear plates of the same hardness class are comparable, not identical. Chemistry, toughness and processing advice differ by mill, so confirm any substitution with the end user.
06Can Abrazo 500 Plates be bent?
Only with large bending radii and die openings, as 500-class plate has limited formability. Follow the mill’s minimum radius for the thickness.
07Can Abrazo 500 Plates be welded?
Yes, with low-hydrogen consumables and the preheat and interpass temperatures the mill gives for the grade and combined thickness.
08What is Abrazo 500 Plates used for?
Typical uses on this page include tipper bodies, cutting edges, crushing machinery and excavator buckets.
09Which certificate should I request?
An EN 10204 3.1 mill test certificate showing the brand and grade, heat number, chemistry and hardness, plus impact results where you specify a test temperature.
10How do I get a price and delivery date?
Send the brand and grade, thickness, size or cutting drawing, quantity, destination and required date through the enquiry form below, by WhatsApp or by phone.
