Q: What is JFE 780 LE Plates?

JFE 780 LE is JFE’s HITEN 780LE plate: a 780 N/mm² class low-alloy high-strength steel, made by TMCP or quenching and tempering, with 685 MPa minimum yield and toughness guaranteed at −40 °C in thicknesses of 5–160 mm.

Q: What is JFE-HITEN 780LE?

It is a 780 N/mm² class high-strength plate from JFE Steel with high weldability and excellent toughness at −40 °C, listed in thicknesses of 5–160 mm (and 160.1–203.2 mm at 610 MPa yield).

Q: Is JFE 780 LE the same as S690QL?

No. It is a Japanese JFE grade of 685 MPa minimum yield and 780–930 MPa tensile strength. It is used as a comparable alternative to S690QL where the design allows it.

Q: What sizes are listed?

Widths up to 5,350 mm and lengths up to 27,000 mm are listed, with separate availability tables for plate with and without heat treatment.

Q: Can JFE 780 LE be welded?

Yes, with low-hydrogen consumables and the preheat and interpass temperatures the mill gives for the grade and combined thickness.

Q: Which certificate should I request?

An EN 10204 3.1 mill test certificate showing the brand and grade, heat number, chemistry and mechanical properties, plus impact results where you specify a test temperature.

Q: Can another brand replace JFE 780 LE?

Brands of the same class are comparable, not identical. Chemistry, toughness, thickness range and processing advice differ by mill, so confirm any substitution with your engineer.

Q: Can JFE 780 LE plate be cut to size?

Yes. Champak Industries lists full and part plate and profile supply and a plasma-cutting service; send drawings, quantities and tolerances with your enquiry.

Q: Which sizes are available?

Availability depends on the grade, mill and thickness; send the thickness, width and length you need and sizes will be confirmed at quotation.

Q: How do I get a price and delivery date?

Send the grade, thickness, size or cutting drawing, quantity, destination and required date through the enquiry form below, by WhatsApp or by phone.

Send Enquiry WhatsApp

High Strength JFE 780 LE Plates is low-alloyed high-strength steel plate manufactured by TMCP, or quenched and tempered. Because Champak offers high strength, it results in a significant reduction in the weight of welded structures. Good WeldabilityJFE 780 LE Plates of which chemical composition is controlled by specific procedure offers low carbon equivalent and excellent weldability.

Source of the text: This page reproduces JFE Steel’s HITEN catalogue, with the mill’s name replaced by “Champak” in places. Statements such as “because Champak offers high strength” describe the JFE-HITEN plate made by JFE. Words run together in the original (“Good WeldabilityJFE…”) are headings: Good Weldability, Excellent Notch Toughness, Excellent Uniformity and Clean Surface, Good Workability and Wide Range of Sizes.

Champak Industries also supplies welding materials suitable for JFE-HITEN effectively, and thereby enjoys acceptances by customers. Excellent Notch Toughness JFE 780 LE Plates offers high notch toughness because it is produced by closely controlling the chemical composition and heat treatment conditions. Application of Champak Industries ensures construction of structures providing high reliability against brittle fracture. Excellent Uniformity and Clean Surface Rolled on the most modern plate mill under rigid quality control, JFE 780 LE Plates has excellent uniformity in properties, flatness and surface finish. In addition, slab surfaces are carefully scarfed, powerful water jets are used during rolling, and nonoxidizing atmosphere furnaces are used for heat treatment. Consequently, JFE 780 LE Plates has smooth and clean surfaces. Good Workability Because JFE 780 LE Plates features good ductility, it offers not only good formability, but also good machinability, making it easy to drill and cut. Wide Range of Sizes JFE Plates are available in widths of up to 5,350mm, and in lengths of up to 27,000mm, and then contributes to saving expenses.

JFE 780 LE Plates: Purchasing Specification

Requirement	What to specify
Grade and standard	EN 10025-6 grade (S690Q, S690QL or S690QL1) or the named brand; state the edition and whether equivalent brands are acceptable.
Impact requirement	Charpy temperature and energy: “L” grades are tested at −40 °C and “L1” grades at −60 °C.
Thickness	Yield and tensile strength fall as thickness rises, so give the thickness range of your plates.
Welding	Preheat and consumables depend on carbon equivalent and thickness; ask for the mill’s welding recommendations.
Documents	EN 10204 3.1 or 3.2 mill certificate, with ultrasonic testing where specified.

JFE'S HIGH TENSILE STRENGTH STEEL PLATE PRODUCTS SPECIFIED BY TYPICAL STANDARDS

Type of Steel		JIS	ASTM	EN	WES **	Ship's class Standard ***	JFE Standard
Steel Plates for Structural Use	590N/mm² Class	G 3106 SM570*	A678 Gr.0 Gr.D A841		HW 450 HW 450CF	A47 D47 E47 F47	JFE-HITEN570U2 JFE-HITEN570E JFE-HITEN590S JFE-HITEN590SL JFE-HITEN590AZ JFE-HITEN590 JFE-HITEN590U2 JFE-HITEN590E
	590N/mm² Class				HW 490 HW 490CF	A51 D51 E51 F51	JFE-HITEN610 JFE-HITEN610U2 JFE-HITEN610E
	690N/mm² Class				HW 550 HW 620	A56 D56 E56 A63, 63N D63, 63N E63	JFE-HITEN690S JFE-HITEN690 JFE-HITEN690M JFE-HITEN710 JFE-HITEN710M
	780N/mm² Class	G 3128 SHY685 SHY685N SHY685NS	A514 A709 Gr.100		HW 685	A70, 70N D70, 70N E70, 70N F70, 70N	JFE-HITEN780EX JFE-HITEN780S JFE-HITEN780LE JFE-HITEN780M
	980N/mm² Class				HW 885		JFE-HITEN980S JFE-HITEN980
Steel Plates for Pressure Vessels	590N/mm² Class	G 3115 SPV450 G 3124 SEV345	A537 Cl. 2 A738 Gr.B A841	EN10028 P460N	HW 450	KPV46	JFE-HITEN570U2 JFE-HITEN570E JFE-HITEN590 JFE-HITEN590U2 JFE-HITEN590E
	590N/mm² Class	G 3115 SPV490			HW 490	KPV50	JFE-HITEN610 JFE-HITEN610U2 JFE-HITEN610E
	690N/mm² Class		A543 Cl. 1		HW 620		JFE-HITEN690M
	780N/mm² Class		A517 A543 Cl. 2		HW 685		JFE-HITEN780M
	980N/mm² Class				HW 885		JFE-HITEN980

Reading the standards table: N/mm² equals MPa. JIS, ASTM and EN are the equivalent standards listed for each class, WES is the Japan Welding Engineering Society standard, and “ship’s class” means classification-society grades. The asterisks refer to footnotes that are not given on the page.

GRADES OF JFE-HITEN

Strength (N/mm2)	Designation	Thickness (mm)	Yield Strength Min. (N/mm2)	Tensile Strength (N/mm2)	Features and Typical Applications
590	JFE-HITEN590 JFE-HITEN610 JFE-HITEN570U2 JFE-HITEN590U2 JFE-HITEN610U2 JFE-HITEN570E JFE-HITEN590E JFE-HITEN610E	6 – 150 6 – 150 6 – 100 6 – 75 6 – 75 6 – 100 6 – 75 6 – 75	450 490 450 450 490 450 450 490	590 – 710 610 – 730 570 – 700 590 – 710 610 – 730 570 – 700 590 – 710 610 – 730	For Bridges, Penstocks, Tanks, Offshore structures U2 : High Tensile Strength Steel Plates with High Weldability E : High Tensile Strength Steel Plates with High Weldability for High Heat Input Welding
590	JFE-HITEN590S JFE-HITEN590SL	6 – 40 6 – 50	450 450	590 – 710 590 – 710	S : Without Heat treatment for Civil Engineering and Industrial Machinery SL : Same as above with excellent toughness at low temperature (-40°C)
690	JFE-HITEN690 JFE-HITEN710	6 – 100 6 – 100	590 620	690 – 820 710 – 840	Ni-free type for Tanks, Offshore Structures etc.
	JFE-HITEN690M JFE-HITEN710M	6 – 100 6 – 100	590 620	690 – 820 710 – 840	Ni type and Low carbon-equivalent for Bridges, Penstocks, Tanks, etc.
	JFE-HITEN690S	6 – 25	550	690 – 830	With reducing alloying elements and without Heat Treatment, for Civil Engineering and Industrial Machinery
780	JFE-HITEN780M	6 – 150	685	780 – 930	Ni type and Low Carbon-equivalent for Bridges, Penstocks, Offshore structures etc.
	JFE-HITEN780EX	6 – 60	685	780 – 930	High Performance with Relaxing Pre-heating for Bridges
	JFE-HITEN780S	5 – 160	685	780 – 930	Reducing alloying elements for Civil Engineering and Industrial Machinery
	JFE-HITEN780LE	5 – 160 160.1 – 203.2	685 610	780 – 930 700 – 850	High Weldability and excellent toughness at low temperature (-40°C), for Civil Engineering and Industrial Machinery
980	JFE-HITEN980	6 – 120	885	950 – 1130	High Strength, High Weldability and Good Toughness for Penstocks
	JFE-HITEN980S	5 – 50.8	885	950 – 1130	For Civil Engineering and Industrial Machinery
	JFE-HITEN980LE	5 – 50.8	900	980 – 1150	High tensile strength steel plate with excellent low temperature toughness (-40°C) for Civil Machinery and Industrial Machinery.
	JFE–HYD960LE	5 – 50.8 50.9 – 63.5	960 930	980 – 1150 950 – 1120	Higher yield strength than conventional 980 grade steel, high weldability and excellent toughness at low temperature (-40°C), for Civil Engineering and Industrial Machinery.
1180	JFE–HYD1100LE	12 – 32	1100	1180 – 1500	High tensile strength steel plate for Civil Machinery and Industrial Machinery. Has high yield stress, and excellent weldability and low temperature toughness (-40°C).

AVAILABLE SIZES

Without Heat Treatment

Width mm_ Thickness mm	1000 _ 1400	1401 _ 1600	1601 _ 1800	1801 _ 2000	2001 _ 2200	2201 _ 2400	2401 _ 2600	2601 _ 2800	2801 _ 3000	3001 _ 3200	3201 _ 3400	3401 _ 3600	3601 _ 3800	3801 _ 4000	4001 _ 4200	4201 _ 4400	4401 _ 4600	4601 _ 4800	4801 _ 5000	5001 _ 5200	5201 _ 5300	5301 _ 5350
6.0 - 6.9	25																22	22	19	16	13.5	13.5
7.0 - 9.0																		22	20	16	13.5	13.5
9.1 - 11.9																			20	20	20	16
12.0 - 13.9	27																			25	22	16
14.0 - 25.0																						16
25.1 - 28.0																	25					16
28.1 - 32.0														25			25		24	23	20	16
32.1 - 38.0											25			25	24	23	22	21	20	19	18	16
38.1 - 45.0					25							24	23	23	20	19	19	18	17	16	16	16
45.1 - 50.0										23	22	21	20	20	18	17	16	16	15	14	14	14
50.1 - 55.0							24	24	21	21	20	19	18	18	16	16	15	14	14	13	13	13
55.1 - 60.0							24	22	21	19	19	17	16	16	15	14	13	13	12	12	12	11
60.1 - 65.0					24	23	21	20	18	18	17	16	15	15	14	13	12	12	11	11	10	9.5
65.1 - 70.0				24	24	22	21	19	18	17	16	15	14	14	13	12	12	11	11	10	10	9.5
70.1 - 75.0	24	23	24	23	21	20	18	17	15	15	15	14	13	13	12	11	11	10	10	9.2	9	8.5
75.1 - 80.0	23	23	22	21	21	19	18	17	15	14	14	13	12	12	11	11	10	10	9.6	9.2	9	8.5
80.1 - 90.0	20	20	20	19	19	17	16	15	14	13	12	11	11	10	10	9.7	9.2	8.8	8.5	8.2	8	7.5
90.1 - 100.0	18	18	18	17	17	15	14	13	12	11	11	10	10	9.6	9.1	8.7	8.3	8	7.6	7.3
100.1 - 110.0	16	16	16	16	15	14	13	12	11	10	10	9.7	9.1	9	8.3	8	7.6	7.2	7	6.7 5.8
110.1 - 120.0	15	15	15	14	14	13	12	11	10	10	9.4	8.8	8.4	8	7.6	7.2	6.9 6.0	6.6 5.8	6	6
120.1 - 130.0	14	14	14	13	13	12	11	10	9.8	9.2	8.6	8.2	7.7	7.3	7.0	6.7 5.8	6	6	5.1	5.3
130.1 - 140.0	13	13	13	12	12	11	10	9.7	9	8.5	8	7.5	7.1	7	6	6	5.1	5.1	5.1	5.3
140.1 - 150.0	12	12	12	11	11	10	9.7	9.1	8.4	7.9	7.4	7	6.7 5.8	6	6	5	5	5

Reading the size tables: The cells appear to give the maximum available length in metres for each width and thickness (the text says plates up to 27,000 mm long), but the original does not label them. “Negotiable range” means by agreement. Confirm sizes with us when you enquire.

Heat Treated

Width mm_ Thickness mm	1000 _ 1600	1601 _ 1800	1801 _ 2000	2001 _ 2200	2201 _ 2400	2401 _ 2600	2601 _ 2800	2801 _ 3000	3001 _ 3200	3201 _ 3400	3401 _ 3600	3601 _ 3800	3801 _ 4000	4001 _ 4200	4201 _ 4400	4401 _ 4600	4601 _ 4800	4801 _ 5000	5001 _ 5200	5201 _ 5300	5301 _ 5350
6.0 - 6.9										22	20	15	13
7.0 - 7.9										25	24	22	20	15
8.0 - 8.9													22	18	16	13	11
9.0 - 9.9															22	20	16	12
10.0 - 11.9																		22	20	18	Negotiable Range
12.0 - 13.9																				22
14.0 - 26.0
26.1 - 28.0
28.1 - 30.0																		24	24	22
30.1 - 35.0														24	24	23	22	21	21	20
35.1 - 40.0												24	23	22	21	20	19	18	18	17
40.1 - 45.0											23	22	20	19	19	18	17	16	16	15
45.1 - 50.0									23	22	20 17	19	18	17	17	16	15	15	14	14 11
50.1 - 60.0					24	24	22	20	19	18	20 17	16	15	14	14	13	13	12	11	14 11
60.1 - 70.0		23	20	24	22	20	19	17	16	15	14	14	13	12	12	11	11	10	10	10
70.1 - 80.0	22	20	18	21	19	18	16	15	14	13	13	12	11	11	10	10	9.7	9.3	8.9	8.7
80.1 - 90.0	20	18	16	19	17	16	14	13	13	12	11	10	10	9.8	9.4	8.9	8.5	8.3	7.9
90.1 - 100.0	18	16	14	17	15	14	13	12	11	10	10	9.8	9.3	8.8	8.4	8.0	7.7	7.3	7.0 67 5.5
100.1 - 110.0	16	14	13	15	14	13	12	11	10	9.9	9.4	8.8	8.4	8.0	7.6	7.3	6, y 6.0	6.6 5.7
110.1 - 120.0	15	13	12	14	13	11	11	10	9.7	9.1	8.5	8.1	7.7	7.3	6.9 6.0	6.6 5.7	6.3 5.8	5.2
120.1 - 130.0	13	12	11	13	11	11	10	9.5	8.9	8.3	7.9	7.3	7.0	6.7	6.4 5.5	5.2	5.0
130.1 - 140.0	11	10	9.7	11	10	9.7	9.4	8.7	8.2	7.7	7.2	6.8	6.5 5.6	5.3	4.8
140.1 - 150.0	10	10	9.6	10	9.7	9.4	8.7	8.1	7.6	7.1	6.7	6.4 5.5	5.2	4.9

JFE-HITEN STANDARDS

JFE-HITEN590 Series and JFE-HITEN690 Series

Designation (Thickness mm)	Heat Treatment	Chemical Composition (%)															Tensile Test＊1）						Bending Test (180° ).2)		*Charpy Impact Test (2mmV) 3)**
		C	Si	Mn	P	S	Cu	Ni	Cr	Mo	V	Nb	B	Ceq		PCM	Yield Strength	(N/mm2)	Tensile Strength (N/mm2)		Elongation (%)		Bending Radius	(Test Specimen No.1)	Test Temperature	（℃）	Absorbed Energy （J）
		C	Si	Mn	P	S	Cu	Ni	Cr	Mo	V	Nb	B	Thickness (mm)		PCM	Thickness (mm)	(N/mm2)	Tensile Strength (N/mm2)	Thickness (mm)	Elongation (%)	Test Specimen	Thickness (mm)	(Test Specimen No.1)	Thickness (mm)	（℃）	Absorbed Energy （J）
JFE-HITEN590 (6 - 150)	QT	≤ 0.16	0.15/0.55	≤ 1.50	≤ 0.025	≤ 0.015	≤ 0.30	≤ 1.00	≤ 0.30	≤ 0.30	≤ 0.08	-	-	t ≤ 50 50< t ≤ 75 75< t	≤ 0.44 ≤ 0.46 ≤ 0.48	≤ 0.26 ≤ 0.28 ≤ 0.28	-	≥ 450	590/710	t ≤ 16 16< t ≤ 50 20< t	≥ 20 ≥ 28 ≥ 20	No.5 No.5 No.4	-	1.5t	12	- 10	≥ 47
JFE-HITEN610 (6 - 150)	QT	≤ 0.16	0.15/0.55	≤ 1.50	≤ 0.025	≤ 0.015	≤ 0.30	≤ 1.00	≤ 0.30	≤ 0.30	≤ 0.08	-	-	t ≤ 50 50< t ≤ 75 75< t	≤ 0.45 ≤ 0.47 ≤ 0.49	≤ 0.26 ≤ 0.28 ≤ 0.28	t ≤ 75 75< t	≥ 490 ≥ 470	610/730	t ≤ 16 16< t ≤ 50 20< t	≥ 19 ≥ 27 ≥ 19	No.5 No.5 No.4	-;	1.5t	12<t ≤ 32 32	- 10 - 15	≥ 47 ≥ 47
JFE-HITEN690 (6 - 100)	QT	≤ 0.16	≤ 0.35	≤ 1.20	≤ 0.025	≤ 0.015	≤ 0.40	≤ 1.00	≤ 0.70	≤ 0.50	≤ 0.08	-	≤ 0.005	t ≤ 50 50< t	≤ 0.54 ≤ 0.58	- -	t ≤ 75 75< t	≥ 590 ≥ 570	690/820	t ≤ 16 16< t ≤ 50 20< t	≥ 17 ≥ 25 ≥ 17	No.5 No.5 No.4	t ≤ 32 32< t	1.5t 2.0t	12<t ≤ 32 32<t ≤ 50 50<t	- 15 - 20 - 30	≥ 47 ≥ 47 ≥ 47
JFE-HITEN710 (6 - 100)	QT	≤ 0.16	≤ 0.35	≤ 1.20	≤ 0.025	≤ 0.015	≤ 0.40	≤ 1.00	≤ 0.70	≤ 0.50	≤ 0.08	-	≤ 0.005	t ≤ 50 50< t	≤ 0.55 ≤ 0.59	- -	t ≤ 75 75< t	≥ 620 ≥ 600	710/840	t ≤ 16 16< t ≤ 50 20< t	≥ 17 ≥ 25 ≥ 17	No.5 No.5 No.4	t ≤ 32 32< t	1.5t . 20t	12<t ≤ 32 32<t ≤ 50 50<t	-15 - 20 - 30	≥ 47 ≥ 47 ≥ 47
JFE-HITEN690M (6 - 100)	OT	≤ 0.14	≤ 0.35	≤ 1.20	≤ 0.015	≤ 0.015	≤ 0.40	0.30/1.30	≤ 0.70	≤ 0.50	≤ 0.05	-	≤ 0.005	t ≤ 50 50< t	≤ 0.53 ≤ 0.57	- -	t ≤ 75 75< t	≥ 590 ≥ 570	690/820	t ≤ 16 16< t ≤ 50 20< t	≥ 17 ≥ 25 ≥ 17	No.5 No.5 No.4	t ≤ 32 32< t	1.5t . 20t	12<t ≤ 32 32<t ≤ 50 50	- 15 - 20 - 30	≥ 47 ≥ 47 ≥ 47
JFE-HITEN710M (6 - 100)	QT	≤ 0.14	≤ 0.35	≤ 1.20	≤ 0.015	≤ 0.015	≤ 0.40	0.30/1.30	≤ 0.70	≤ 0.50	≤ 0.05	-	≤ 0.005	t ≤ 50 50< t	≤ 0.53 ≤ 0.57	- -	t ≤ 75 75< t	≥ 620 ≥ 600	710/840	t ≤ 16 16< t ≤ 50 20< t	≥ 17 ≥ 25 ≥ 17	No.5 No.5 No.4	t ≤ 32 32< t	1.5t . 20t	12<t ≤ 32 32<t ≤ 50 50	- 15 - 20 - 30	≥ 47 ≥ 47 ≥ 47

Reading the standards tables: QT is quenched and tempered, Ceq and PCM are carbon-equivalent and weld-cracking parameters, and t is plate thickness in mm. Chemistry is in per cent, strengths in N/mm², and impact energy in joules at the test temperature shown.

JFE-HITEN780 Series and JFE-HITEN980

Designation (Thickness mm)	Heat Treatment	Chemical Composition (%)																Tensile Test＊1）						Bending Test (180° ).2)		*Charpy Impact Test (2mmV) 3)**
		Thickness (mm)	C	Si	Mn	P	S	Cu	Ni	Cr	Mo	V	Nb	B	Ceq		PCM	Yield Strength	(N/mm2)	Tensile Strength (N/mm2)		Elongation (%)		Bending Radius	(Test Specimen No.1)	Test Temperature	（℃）	Absorbed Energy （J）
		Thickness (mm)	C	Si	Mn	P	S	Cu	Ni	Cr	Mo	V	Nb	B	Thickness (mm)		PCM	Thickness (mm)	(N/mm2)	Tensile Strength (N/mm2)	Thickness (mm)	Elongation (%)	Test Specimen	Thickness (mm)	(Test Specimen No.1)	Thickness (mm)	（℃）	Absorbed Energy （J）
JFE-HITEN780M (6-150)	QT	ｔ≤ 100 100<t	≤ 0.14 ≤ 0.18	≤ 0.35 ≤ 0.35	≤ 1.20 ≤ 1.20	≤ 0.015 ≤ 0.015	≤ 0.015 ≤ 0.015	≤ 0.50 ≤ 0.50	0.30/1.50 0.30/1.50	≤ 0.70 ≤ 0.80	≤ 0.60 ≤ 0.60	≤ 0.05 ≤ 0.05	- -	≤ 0.005 ≤ 0.005	t ≤ 50 50< t ≤ 100 100< t	≤ 0.53 ≤ 0.57 ≤ 0.62	≤ 0.30 ≤ 0.32 ̶	t ≤ 75 75< t	≥ 685 ≥ 665	780/930	t< 16 16< t < 50 20< t	> 16 ≥ 24 ≥ 16	No.5 No.5 No.4	t < 32 32< t	1.5t 2.0t	12<t < 32 32<t < 50 50<t	-20 - 25 - 35	≥ 47 ≥ 47 ≥ 47
JFE-HITEN980 (6 - 120)	OT	-	≤ 0.14	≤ 0.35	≤ 1.20	≤ 0.010	≤ 0.005	≤ 0.70	≤ 4.00	≤ 0.80	≤ 0.80	≤ 0.15	≤ 0.02	≤ 0.005	t ≤ 50 50< t ≤ 100 100< t	≤ 0.59 ≤ 0.62 ≤ 0.71	≤ 0.29 ≤ 0.33 ≤ 0.36	t ≤ 75 75< t ≤ 100 100< t	≥ 885 ≥ 865 ≥ 865	950/1130 950/1130 930/1110	t ≤ 16 16< t ≤ 50 20< t	≥ 12 ≥ 19 ≥ 12	No.5 No.5 No.4	t ≤ 32 32< t	2.0t 2.5t	12	- 60	≥ 47

Typing errors: The HITEN980 row is marked “OT”, which should read QT.

High Tensile Strength Steel Plates with Good Weldability

Designation (Thickness mm)	Heat Treatment	Chemical Composition (%)															Tensile Test＊1）						Bending Test (180° ).2)		*Charpy Impact Test (2mmV) 3)**
		C	Si	Mn	P	S	Cu	Ni	Cr	Mo	V	Nb	B	Ceq		PCM	Yield Strength	(N/mm2)	Tensile Strength (N/mm2)		Elongation (%)		Bending Radius	(Test Specimen No.1)	Test Temperature	（℃）	Absorbed Energy （J）
		C	Si	Mn	P	S	Cu	Ni	Cr	Mo	V	Nb	B	Thickness (mm)		PCM	Thickness (mm)	(N/mm2)	Tensile Strength (N/mm2)	Thickness (mm)	Elongation (%)	Test Specimen	Thickness (mm)	(Test Specimen No.1)	Thickness (mm)	（℃）	Absorbed Energy （J）
JFE - HITEN570U2 （6 – 100）	QT	≤ 0.09	0.15/0.55	≤ 1.60	≤ 0.025	≤ 0.010	≤ 0.30	≤ 0.30	≤ 0.30	≤ 0.30	≤ 0.06	≤ 0.03	-	-	-	≤ 0.20	t ≤ 16 16< t ≤ 40 40< t ≤ 75 75< t	≥ 460 ≥ 450 ≥ 430 ≥ 420	570/700	t ≤ 16 16< t ≤ 50 20< t	≥ 20 ≥ 28 ≥ 20	No.5 No.5 No.4	t ≤ 32 32< t	1.5t 2.0t	12< t	－ 5	≥ 47
JFE - HITEN590E （6 – 75）	QT	≤ 0.09	0.15/0.55	1.00/1.60	≤ 0.020	≤ 0.010	≤ 0.30	≤ 0.30	≤ 0.30	≤ 0.30	≤ 0.06	≤ 0.03	-	-	-	≤ 0.20	-	≥ 450	590/710	t ≤ 16 16< t ≤ 50 20< t	≥ 20 ≥ 28 ≥ 20	No.5 No.5 No.4	t ≤ 32 32< t	1.5t 2.0t	6≤ t ≤ 20 20< t ≤ 32 32< t ≤ 50 50< t	5 － 5 － 10 － 20	≥ 47 ** ≥ 47 ≥ 47 ≥ 47
JFE - HITEN610E （6 – 75）	QT	≤ 0.09	0.15/0.55	1.20/1.60	≤ 0.025	≤ 0.010	≤ 0.30	≤ 0.30	≤ 0.30	≤ 0.30	≤ 0.06	≤ 0.03	-	-	-	≤ 0.20	－	≥ 490	610/730	t ≤ 16 16< t ≤ 50 20< t	≥ 19 ≥ 27 ≥ 19	No.5 No.5 No.4	t ≤ 32 32< t	1.5t 2.0t	6≤ t ≤ 20 20< t ≤ 32 32< t ≤ 50 50< t	0 － 5 － 15 － 25	≥ 47 ** ≥ 47 ≥ 47 ≥ 47
JFE - HITEN780EX （6 – 60）	QT	≤ 0.09	≤ 0.55	0.60/1.50	≤ 0.015	≤ 0.010	≤ 0.50	0.30/1.50	≤ 0.80	≤ 0.60	≤ 0.05	≤ 0.03	≤ 0.005	t ≤ 34 34< t ≤ 60	≤ 0.53 * ≤ 0.57 *	≤ 0.23 ≤ 0.25	t ≤ 50 50< t ≤ 60	≥ 685 ≥ 665	780/930 760/910	t ≤ 16 16< t ≤ 50 20< t	≥ 16 ≥ 24 ≥ 16	No.5 No.5 No.4	t ≤ 32 32< t	1.5t 2.0t	12< t ≤ 32 32< t ≤ 60	－ 20 － 25	≥ 47 ≥ 47

High Tensile Strength Steel Plates for High Heat-input Welding

Designation (Thickness mm)	Heat Treatment	Chemical Composition (%)													Tensile Test＊1）						Bending Test (180° ).2)		*Charpy Impact Test (2mmV) 3)**
		C	Si	Mn	P	S	Cu	Ni	Cr	Mo	V	Nb	B	PCM	Yield Strength	(N/mm2)	Tensile Strength (N/mm2)		Elongation (%)		Bending Radius	(Test Specimen No.1)	Test Temperature	（℃）	Absorbed Energy （J）
		C	Si	Mn	P	S	Cu	Ni	Cr	Mo	V	Nb	B	PCM	Thickness (mm)	(N/mm2)	Tensile Strength (N/mm2)	Thickness (mm)	Elongation (%)	Thickness (mm)	Test Specimen	(Test Specimen No.1)	Thickness (mm)	（℃）	Absorbed Energy （J）
JFE - HITEN570E （6 – 100）	QT	≤ 0.09	0.15/0.55	≤ 1.60	≤ 0.020	≤ 0.010	≤ 0.30	≤ 0.30	≤ 0.30	≤ 0.30	≤ 0.06	≤ 0.03	-	≤ 0.20	t ≤ 16 16< t ≤ 40 40< t ≤ 75 75< t	≥ 460 ≥ 450 ≥ 430 ≥ 420	570/700	t ≤ 16 16< t ≤ 50 20< t	≥ 20 ≥ 28 ≥ 20	No.5 No.5 No.4	t ≤ 32 32< t	1.5t 2.0t	12< t	－ 5	≥ 47
JFE - HITEN590E （6 – 75）	QT	≤ 0.09	0.15/0.55	1.00/1.60	≤ 0.020	≤ 0.010	≤ 0.30	≤ 0.30	≤ 0.30	≤ 0.30	≤ 0.06	≤ 0.03	-	≤ 0.20	-	≥ 450	590/710	t ≤ 16 16< t ≤ 50 20< t	≥ 20 ≥ 28 ≥ 20	No.5 No.5 No.4	t ≤ 32 32< t	1.5t 2.0t	6≤ t ≤ 20 20< t ≤ 32 32< t ≤ 50 50< t	5 － 5 － 10 － 20	≥ 47** ≥ 47 ≥ 47 ≥ 47
JFE - HITEN610E （6 – 75）	QT	≤ 0.09	0.15/0.55	1.00/1.60	≤ 0.020	≤ 0.010	≤ 0.30	≤ 0.30	≤ 0.30	≤ 0.30	≤ 0.06	≤ 0.03	-	≤ 0.20	-	≥ 490	610/730	t ≤ 16 16< t ≤ 50 20< t	≥ 19 ≥ 27 ≥ 19	No.5 No.5 No.4	t ≤ 32 32< t	1.5t 2.0t	6≤ t ≤ 20 20< t ≤ 32 32< t ≤ 50 50< t	0 － 5 － 15 － 25	≥ 47** ≥ 47 ≥ 47 ≥ 47

High Tensile Strength Steel Plates for Civil Engineering and Industrial Machinery

Designation (Thickness mm)	Heat Treatment	Chemical Composition (%)															Tensile Test＊1）						Bending Test (180° ).2)		*Charpy Impact Test (2mmV) 3)**
		Thickness (mm)	C	Si	Mn	P	S	Cu	Ni	Cr	Mo	V	Nb	B	Ceq	PCM	Yield Strength	(N/mm2)	Tensile Strength (N/mm2)		Elongation (%)		Bending Radius	(Test Specimen No.1)	Test Temperature	（℃）	Absorbed Energy （J）
		Thickness (mm)	C	Si	Mn	P	S	Cu	Ni	Cr	Mo	V	Nb	B	Ceq	PCM	Thickness (mm)	(N/mm2)	Tensile Strength (N/mm2)	Thickness (mm)	Elongation (%)	Thickness (mm)	Test Specimen	(Test Specimen No.1)	Thickness (mm)	（℃）	Absorbed Energy （J）
JFE - HITEN590SA (6 – 40)	CR or TMCP	-	≤ 0.18	≤ 0.55	≤ 2.00	≤ 0.030	≤ 0.020	Other elements are added as required.							≤ 0.45	-	-	≥ 450	590/710	t ≤ 16 16< t ≤ 50 20< t	≥ 20 ≥ 28 ≥ 20	No.5 No.5 No.4	t ≤ 32 32< t	1.5t 2.0t	-	-	-
JFE - HITEN590SB (6 – 40)	CR or TMCP	-	≤ 0.18	≤ 0.55	≤ 2.00	≤ 0.030	≤ 0.015	Other elements are added as required.							≤ 0.45	-	-	≥ 450	590/710	t ≤ 16 16< t ≤ 50 20< t	≥ 20 ≥ 28 ≥ 20	No.5 No.5 No.4	t ≤ 32 32< t	1.5t 2.0t	12< t	- 10	≥ 47
JFE - HITEN590SL（6 – 50）	CR or TMCP	-	≤ 0.16	0.20/0.55	0.80/1.60	≤ 0.030	≤ 0.015	-	-	-	≤ 0.35	≤ 0.08	≤ 0.05	-	≤ 0.46	≤ 0.22	t ≤ 32 32< t	≥ 450 ≥ 430	590/710 570/705	t ≤ 16 16< t ≤ 20 20< t	≥ 20 ≥ 26 ≥ 20	No.5 No.5 No.4	-	1.5t	6 ≤ t ≤ 36 36< t	- 40 - 20	≥ 27 ** ≥ 27
JFE - HITEN690S（6 – 25）	CR or TMCP	-	≤ 0.15	≤ 0.55	≤ 2.00	≤ 0.030	≤ 0.015	Other elements such as Nb, V and Ti are added as required.							≤ 0.50	-	-	≥ 550	690/830	t ≤ 16 16< t	≥ 17 ≥ 25	No.5 No.5	-	1.5t	12< t	- 10	≥ 47
JFE - HITEN780S （5 – 160）	QT	t ≤ 50	≤ 0.25	≤ 0.55	≤ 1.60	≤ 0.030	≤ 0.015	-	-	≤ 0.70	≤ 0.30	≤ 0.10	Ti:0.005/0.02	≤ 0.005	≤ 0.53	-	t ≤ 75 75< t ≤ 160	≥ 685 ≥ 665	780/930 780/930	t ≤ 16 16< t ≤ 32 20< t	≥ 16 ≥ 24 ≥ 16	No.5 No.5 No.4	t ≤ 32 32< t	1.5t 2.0t	5≤ t ≤ 12 12< t ≤ 20 20< t ≤ 32 32< t ≤ 160	- - 5 - 15 - 20	- ≥ 35 ≥ 35 ≥ 35
		50< t ≤ 100	≤ 0.20					≤ 0.50	≤ 0.50	≤ 1.50	≤ 0.60		Ti:0.005/0.02	≤ 0.61
		100< t ≤ 160	≤ 0.18					≤ 0.50	≤ 0.50	≤ 1.50	≤ 0.60		Ti: ≤ 0.03	≤ 0.70
JFE - HITEN780LE（5 – 203.2）	QT or TMCP	t ≤ 19 19< t ≤ 32 32< t ≤ 50 50< t ≤ 70 70< t ≤ 160 160< t ≤ 203.2	≤ 0.20	≤ 0.40	≤ 1.40	≤ 0.025	≤ 0.015	-	-	≤ 0.20	≤ 0.15	≤ 0.08	≤ 0.03	≤ 0.005	≤ 0.40*	-	-	≥ 685	780/930	t ≤ 16 16< t ≤ 40 20< t	≥ 16 ≥ 24 ≥ 16	No.5 No.5 No.4	t ≤ 32 32< t	1.5t 2.0t	5≤ t < 6 6≤ t < 12 12≤ t ≤ 160 160< t ≤ 203.2	— - 40 - 40 - 40	— ≥ 40 *** ≥ 40 ≥ 35
										≤ 0.20	≤ 0.15				≤ 0.43*
										≤ 0.80	≤ 0.40				≤ 0.53*
										≤ 0.80	≤ 0.40				≤ 0.65*
			≤ 0.18							≤ 1.50	≤ 0.80	≤ 0.10			≤ 0.73*
			≤ 0.18	≤ 0.55	≤ 1.60			≤ 0.60	≤ 0.75	≤ 1.50	≤ 0.80	≤ 0.10	Ti: ≤ 0.03		≤ 0.78*		160< t ≤ 203.2	≥ 610	700/850
JFE - HITEN980S（5 – 50.8）	QT	-	≤ 0.18	≤ 0.35	≤ 1.20	≤ 0.020	≤ 0.020	≤ 0.70	≤ 2.00	≤ 0.80	≤ 0.80	≤ 0.08	≤ 0.02	≤ 0.005	≤ 0.65	-	-	≥ 885	950/1130	t ≤ 16 16< t ≤ 50.8 20< t	≥ 12 ≥ 19 ≥ 12	No.5 No.5 No.4	t ≤ 32 32< t	2.0t 2.5t	5≤ t ≤ 12 12< t ≤ 20 20< t ≤ 32 32< t	— - 10 - 25 - 30	— ≥ 35 ≥ 35 ≥ 35
JFE - HITEN980LE （5 – 50.8）	QT	t ≤ 32 32< t ≤ 50.8	≤ 0.18	≤ 0.40	≤ 1.40	≤ 0.020	≤ 0.015	-	-	≤ 0.80 ≤ 1.50	≤ 0.60 ≤ 0.80	≤ 0.10	≤ 0.03	≤ 0.005	≤ 0.58* ≤ 0.65*	-	-	≥ 900	980/1150	t ≤ 16 16< t ≤ 50.8 20< t	≥ 12 ≥ 19 ≥ 12	No.5 No.5 No.4	t ≤ 32 32<	2.0t 2.5t	5≤ t < 6 6≤ t < 12 12≤ t < 50.8	— - 40 - 40	— ≥ 40 *** ≥ 40
JFE – HYD960LE （5 – 63.5）	QT or TMCP	t ≤ 32	≤ 0.18	≤ 0.70	≤ 1.70	≤ 0.020	≤ 0.010	-	-	≤ 1.00	≤ 0.60	≤ 0.08	-	≤ 0.004	≤ 0.64*	-	t ≤ 50.8	≥ 960	980/1150	t ≤ 40 40< t	≥ 12	No.5 No.4	-	3.0t	5≤ t < 6 6≤ t ≤ 63.5	— - 40	— ≥ 27****
		32< t ≤ 50.8	≤ 0.20								≤ 0.90				≤ 0.70*		t ≤ 50.8	≥ 960	980/1150
		50.8< t ≤ 63.5	≤ 0.20								≤ 0.90				≤ 0.70*		50.8< t ≤ 63.5	≥ 930	950/1120
JFE – HYD1100LE （12 – 32）	TMCP	-	≤ 0.20	≤ 0.70	≤ 1.70	≤ 0.020	≤ 0.010	-	-	— ≤ 1.00	≤ 0.90	≤ 0.08	-	≤ 0.004	≤ 0.70*	-	-	≥ 1100	1180/1500	-	≥ 12	No.5	-	4.0t	-	- 40	≥ 27

Dimensional Tolerance, Shape, and Appearance

Designation	Dimensional Tolerance, Shape, and Appearance
590, 590U2, 590E 610, 610U2, 610E 690, 690M, 710, 710M 780M 980	Dimensional tolerances of thickness, width, and length, flatness, and shape are in accordance with JIS G 3115.
570U2, 570E 590S, 590SL 690S 780S, 780LE, 780EX 980S, 980LE, HYD960LE, HYD1100LE	Dimensional tolerances of thickness, width, and length, flatness, and shape are in accordance with JIS G 3193.

TYPICAL PROPERTIES OF JFE-HITEN

JFE-HITEN 610U2 ─ 590N/mm2 Class High Tensile Strength Steel Plates with good Weldability

Chemical composition

Designation	Th ic (mmkne)ss	C	Si	Mn	P	S	Pcm
JFE-HITEN610U2	75	0.08	0.26	1 44	0.005	0.002	0.18
Conventional 590N/mm2g rade	50	0.13	0.26	1.29	0.011	0.003	0.23

Garbled cells: “Th ic (mmkne)ss” means Thickness (mm), “1 44” means 1.44 and “Conventional 590N/mm2g rade” means conventional 590 N/mm² grade.

Mechanical properties of plate

Designation	Tensile test			Charpy impact test
Designation	YS (N/mm2)	TS (N/mm2)	El* (%)	Temp. (t)	Dir.	Absorbed energy (J)
JFE-HITEN610U2	534	624	31*	- 10	L	275
Conventional 590N/mm2g rade	566	668	50	- 10	L	269

JFE-HITEN 610E ─ 590N/mm2 Class High Tensile Strength Steel Plates for High Heat-input Welding

Chemical composition

Designation	Th ic (mmkne)ss	C	Si	Mn	P	S	Pcm
JFE-HITEN610E	25	0.08	0.20	1.33	0.008	0.003	0.17

Mechanical properties of electro-gas arc welded joint

Welding condition			Tensile strength of welded joint (N/mm2)	Charpy impact test
Groove configuration	Welding material	Heat input (kJ/mm)	Tensile strength of welded joint (N/mm2)	Test location	Test temp. (°C)	Absorbed energy (J)
	DWS–1LG	120	617 618	Weld metal	0	113
				Weld metal	- 25	82
				Fusion line	0	244
				Fusion line	- 25	171
				Center of HAZ	0	271
				Center of HAZ	- 25	171

JFE-HITEN 780EX ─ 780N/mm2 Class High Tensile Strength Steel Plates with High Weldability

Chemical composition

Designation	Thickness (mm)	C	Si	Mn	P	S	Pcm
JFE-HITEN780EX	34	0.08	0.20	1.05	0.004	0.001	0.22

Mechanical properties of plate

Tensile test			Charpy impact test
YS	TS	El*	Temp.	Dir.	Absorbed energy
(N/mm2)	(N/mm2)	(%)	(°C)		(J)
769	844	24	- 40	L	286

JFE-HITEN 980 ─ 980N/mm2 Class High Tensile Strength Steel Plates with High Weldability

Chemical composition

Thickness (mm)	C	Si	Mn	P	S	Pcm
75	0.09	0.25	1.14	0.005	0.001	0.27

Mechanical properties of plate

Tensile test（1/4 t）			Charpy impact test（1/4 t）
YS	TS	El*	Temp.	Dir.	Absorbed energy
(N/mm2)	(N/mm2)	(%)	(°C)		(J)
930	977	25	0	C	208
930	977	25	- 60	C	158

Mechanical properties of submerged arc welded joint

Welding condition			Tensile strength of welded joint (N/mm2)	Charpy impact test
Groove configuration	Welding material	Heat input (kJ/mm)	Tensile strength of welded joint (N/mm2)	Test location	Test temp. (t)	Absorbed energy (J)
	PFH-100J/US -100J	45	977 981	Weld metal	- 10	109
				Fusion line		136
				Center of HAZ		248

Choosing a Quenched and Tempered Structural Plate

These brands are all quenched and tempered high-yield structural steels used where design strength is limited by plate weight. They are comparable in strength class but not identical: thickness range, chemistry, toughness grades and welding advice differ by mill.

Brand	Basis	Notes from the pages
S690 QL	EN 10025-6 grade, 690 MPa minimum yield up to 50 mm	Impact guaranteed at −40 °C; start here if the brand is not fixed
DILLIMAX 690	Dillinger brand, in B, T and E qualities (S690Q, S690QL, S690QL1)	B at −20 °C, T at −40 °C, E at −60 °C; 6–255 mm (B, T)
WELDOX 700	SSAB brand, in E and F qualities	E at −40 °C, F at −60 °C; 4–160 mm (E), 4–130 mm (F)
NAXTRA 70	S690QL-class quenched and tempered structural steel	Machine building, lifting equipment, heavy transport
SUPRALSIM 690	Quenched and tempered, 690 N/mm² minimum yield, low sulphur and phosphorus	Weight-saving structures; forming and welding
MAXIL 690	690 MPa-class brand listed with the other high-strength steels	Ask for the datasheet
JFE 780 LE (this page)	JFE HITEN 780 N/mm² class, 685 MPa minimum yield	Impact at −40 °C; 5–160 mm

Use the grade and brand approved in your design; confirm any substitution with your engineer.

Related plates in this range

Applications for JFE 780 LE Plates

Ore-Processing plant with conveyors and crushing equipment — Mining, earthmoving and heavy equipment

Typical uses include cranes, lifting equipment, heavy transport, machine building and welded steel structures. Tell us the load, temperature and service conditions so the right grade and thickness can be quoted.

Cutting, Fabrication and Welding

Champak Industries describes full and part plate/profile supply and a plasma-cutting service. Send drawings, quantities, tolerances and edge preparation for your parts. High-strength plate needs controlled preheat, interpass temperature and heat input when welding, and forming limits depend on the grade and thickness; follow the mill’s recommendations.

Testing, Inspection Documents and Traceability

Requirement	What to identify in the order
Mill test certificate	EN 10204 3.1 showing brand and grade, heat number, chemistry and mechanical properties
Impact test	Charpy test temperature and minimum energy, if required
Ultrasonic test	Standard and acceptance class, if required
Traceability	Heat and plate number transferred to cut pieces

See the company’s Quality Policy for its published policy.

Source JFE 780 LE Plates from Champak Industries

Champak Industries’ company profile records its establishment in Mumbai in 1978 and its stockist, import and export activities. JFE 780 LE Plates can be requested together with other plates in the High Tensile Plates range.

What Determines the Quotation?

Grade and brand, thickness, plate size, quantity, cutting, testing and packing all affect the quotation. Say whether pricing is needed per kilogram, per plate or per finished piece.

Packing, Dispatch and Export Requirements

Give the delivery address, required date and unloading constraints. For export orders, include the destination port, delivery terms and document list.

WANT TO KNOW MORE?

Send Enquiry

or call

0982 0944 724

We Supply JFE 780 LE Plates in listed cities in India

Mumbai, Lucknow, Coimbatore, Imphal, Mysore, Ratlam, Delhi, Kanpur, Darjeeling, Jalandhar, Nagpur, Solapur, Kolkata, Allahabad, Dehradun, Jammu, Nashik, Srinagar, Chennai, Ahmedabad, Faridabad, Jamshedpur, Bhadravati, Chattisgarh, Durgapur, Asansol, Hospet, Bellary, Visakhapatnam, Nellore, Surat, Bangalore, Chandigarh, Ghaziabad, Jhansi, Patna, Siliguri, Hyderabad, Stainless Steel Pipe dealers in Salem, Amritsar, Noida, Kochi (Cochin), Mangalore, Indore, Vadodra, Bhubaneswar, Bikaner, Bhavnagar, Tirupur, Ankleshwar, Warangal, Agartala, Thoothukudi, Stainless Steel Pipe suppliers in Pune, We offer fastest delivery in India including Thiruvanthapuram, Jaipur, Aizawl, Guwahati, Kozhikode, Raipur, Vishakhapatnam, Jabalpur, Bhopal, Gwalior, Ludhiana, Rajahmundry, Thane, Agra, Bhubaneshwar, Gurgaon, Madurai, Rajkot, Varanasi, Bhilai, Haridwar, Meerut, Ranchi, Ahmednagar, Akola, Amravati, Aurangabad, Baramati, Beed, Bhandara, Bhiwandi, Buldhana, Chandrapur, Chimur, Dahanu, Dhule, Dindori, Erandol, Gadchiroli, Hatkanangle, Hingoli, Ichalkaranji, Jalgaon, Jalna, Karad, Khed, Yavatmal, Kolaba, Kolhapur, Kopargaon, Latur, Malegaon, Mumbai, Nagpur, Nanded, Nandurbar, Nashik, Osmanabad, Pandharpur, Parbhani, Rajapur, Ramtek, Ratnagiri, Raver, Sangli, Satara, Shirdi, Shirur, Solapur, Thane, Wardha, Washim, Andhra Pradesh, Jammu and Kashmir, Nagaland, Uttarakhand, Haryana, Lakshadweep, Arunachal Pradesh, Jharkhand, Odisha, West Bengal, Himachal Pradesh, Assam, Karnataka, Punjab, Andaman and Nicobar Islands, Puducherry, Bihar, Kerala, Rajasthan, Chandigarh, Meghalaya, Chhattisgarh, Madhya Pradesh, Sikkim, Dadar and Nagar Haveli, Mizoram, Goa, Maharashtra, Tamil Nadu, Daman and Diu, Tripura, Gujarat, Manipur, Telangana, Delhi, Uttar Pradesh in India.

Location note: The phrases “Stainless Steel Pipe dealers in Salem” and “Stainless Steel Pipe suppliers in Pune” in the list above refer to the cities of Salem and Pune. This page does not cover stainless steel pipe.

We Supply and Export in listed Country

United States of America, Malaysia, UAE, Indonesia, Saudi Arabia, Iran, Qatar, India, China, United Kingdom, Singapore, Canada, Thailand, South Korea, Turkey, Philippines, Egypt, Germany, Italy, Japan, Russia, Vietnam, Australia, South Africa, Portugal, Morocco, Costa Rica, Kazakhstan, Netherlands, Mexico, Brazil, France, Spain, Taiwan, Nigeria, Bangladesh, Kuwait, Iraq, Ukraine, Poland, Jordan, Romania, Oman, Hong Kong, Venezuela, Colombia, Norway, Chile, Trinidad & Tobago, Greece, Czechia, Belgium, Sri Lanka, Cyprus, Angola, Myanmar (Burma), United Kingdom, Canada, South Korea, Thailand, Netherlands, Spain, Turkey, Australia, Mexico, Pakistan, Vietnam, Brazil, Philippines, France, Taiwan, Poland, South Africa, Russia, Nigeria, Kuwait, Czechia, Norway, Romania, Egypt, Oman, Sweden, Belgium, Hong Kong, Israel, Colombia, Switzerland, Denmark, Finland, Argentina, Venezuela, Peru, Ukraine, Chile, Bangladesh, Portugal, Ireland, Austria, Algeria, Greece, Iraq, New Zealand, Slovakia, Hungary, Kazakhstan, Slovenia, Lithuania, Serbia, Sri Lanka, Bahrain, Bulgaria, Morocco, Tunisia, Croatia, Jordan, Ecuador, Trinidad & Tobago, Estonia, Azerbaijan, Ghana, Lebanon, Cyprus, Dominican Republic, Latvia, Libya, Costa Rica, Cambodia, Macedonia (FYROM), Belarus, Jamaica, Palestine, Turkmenistan

JFE 780 LE Plates: Frequently Asked Questions

What is JFE 780 LE Plates?

JFE 780 LE is JFE’s HITEN 780LE plate: a 780 N/mm² class low-alloy high-strength steel, made by TMCP or quenching and tempering, with 685 MPa minimum yield and toughness guaranteed at −40 °C in thicknesses of 5–160 mm.

What is JFE-HITEN 780LE?

It is a 780 N/mm² class high-strength plate from JFE Steel with high weldability and excellent toughness at −40 °C, listed in thicknesses of 5–160 mm (and 160.1–203.2 mm at 610 MPa yield).

Is JFE 780 LE the same as S690QL?

No. It is a Japanese JFE grade of 685 MPa minimum yield and 780–930 MPa tensile strength. It is used as a comparable alternative to S690QL where the design allows it.

What sizes are listed?

Widths up to 5,350 mm and lengths up to 27,000 mm are listed, with separate availability tables for plate with and without heat treatment.

Can JFE 780 LE be welded?

Yes, with low-hydrogen consumables and the preheat and interpass temperatures the mill gives for the grade and combined thickness.

Which certificate should I request?

An EN 10204 3.1 mill test certificate showing the brand and grade, heat number, chemistry and mechanical properties, plus impact results where you specify a test temperature.

Can another brand replace JFE 780 LE?

Brands of the same class are comparable, not identical. Chemistry, toughness, thickness range and processing advice differ by mill, so confirm any substitution with your engineer.

Can JFE 780 LE plate be cut to size?

Yes. Champak Industries lists full and part plate and profile supply and a plasma-cutting service; send drawings, quantities and tolerances with your enquiry.

Which sizes are available?

Availability depends on the grade, mill and thickness; send the thickness, width and length you need and sizes will be confirmed at quotation.

How do I get a price and delivery date?

Send the grade, thickness, size or cutting drawing, quantity, destination and required date through the enquiry form below, by WhatsApp or by phone.

JFE 780 LE Plates

JFE 780 LE Plates: Purchasing Specification

JFE'S HIGH TENSILE STRENGTH STEEL PLATE PRODUCTS SPECIFIED BY TYPICAL STANDARDS

GRADES OF JFE-HITEN

AVAILABLE SIZES

Without Heat Treatment

Heat Treated

JFE-HITEN STANDARDS

JFE-HITEN590 Series and JFE-HITEN690 Series

JFE-HITEN780 Series and JFE-HITEN980

High Tensile Strength Steel Plates with Good Weldability

High Tensile Strength Steel Plates for High Heat-input Welding

TYPICAL PROPERTIES OF JFE-HITEN

JFE-HITEN 610U2 ─ 590N/mm2 Class High Tensile Strength Steel Plates with good Weldability

JFE-HITEN 610E ─ 590N/mm2 Class High Tensile Strength Steel Plates for High Heat-input Welding

Chemical composition

Mechanical properties of electro-gas arc welded joint

JFE-HITEN 780EX ─ 780N/mm2 Class High Tensile Strength Steel Plates with High Weldability

Chemical composition

Mechanical properties of plate

JFE-HITEN 980 ─ 980N/mm2 Class High Tensile Strength Steel Plates with High Weldability

Chemical composition

Mechanical properties of plate

Mechanical properties of submerged arc welded joint

Choosing a Quenched and Tempered Structural Plate

Related plates in this range

Applications for JFE 780 LE Plates

Cutting, Fabrication and Welding

Testing, Inspection Documents and Traceability

Source JFE 780 LE Plates from Champak Industries

What Determines the Quotation?

Packing, Dispatch and Export Requirements

JFE 780 LE Plates: Frequently Asked Questions

What is JFE 780 LE Plates?

What is JFE-HITEN 780LE?

Is JFE 780 LE the same as S690QL?

What sizes are listed?

Can JFE 780 LE be welded?

Which certificate should I request?

Can another brand replace JFE 780 LE?

Can JFE 780 LE plate be cut to size?

Which sizes are available?

How do I get a price and delivery date?

JFE 780 LE Plates for Buyers in Other Countries

Request a Quote for JFE 780 LE Plates

Your RFQ Checklist

Send Your Enquiry to Champak Industries

Related Plates and Purchasing Resources
