Champak Industries' is a specialist supplier and exporter of High strength steels S690 QL Plates.We understand customers whose requirement for High strength steels Plates is extreme and who cannot use inferior quality steel plates.
S690 QL, S690 QL high yield Steel plates, High strength steels S690 QL Plates
S690 QL is a high return structural steel evaluation created in consistence with EN 10025:6:2004.
Reading the text: Several sentences on this page are machine-paraphrased. “High return structural steel evaluation” means high-yield structural steel grade, “extinguish and temper” means quench and temper, “bowing” means bending, and “overwhelming work” means heavy duty. The current edition of the standard is EN 10025-6 (the older EN 10137-2 was withdrawn).
S690 QL, S690 QL high yield Steel plates, High strength steels S690 QL Plates.
S690 QL material is high temperature treated utilizing the extinguish and temper transform and has great bowing and welding properties.
Because of the materials high quality nature, utilizing S690ql will advance leaner outlined structures with expanded payload limit and vitality proficiency.
Champak Industries offering an extensive variety of overwhelming work structural steel to clients. Scaffold plate and building structure boards steel sheet are accessible in different evaluations like straight review, low carbon evaluation and high carbon evaluation as indicated by the prerequisite of our client.
General steel range: The sentence about bridge plate, building plate and “straight review, low carbon and high carbon” grades describes a general range of structural steels, not S690 QL, which is one alloy quenched and tempered grade.
It would be ideal if you allude to the specialized subtle elements beneath alluding to S690 QL.
S690 QL - Grade Designation
The grade designation of S690 QL is the following: S = Structural Steel
690 = minimum yield strength (MPa)
Q = Quenching & Tempering
L = Low notch toughness testing temperature
Impact grade: “L” means impact energy is guaranteed at −40 °C (30 J longitudinal, 27 J transverse in the table below); “L1” is the −60 °C grade, which this page does not list.
S690 QL Plates: Purchasing Specification
| Requirement | What to specify |
|---|---|
| Grade and standard | EN 10025-6 grade (S690Q, S690QL or S690QL1) or the named brand; state the edition and whether equivalent brands are acceptable. |
| Impact requirement | Charpy temperature and energy: “L” grades are tested at −40 °C and “L1” grades at −60 °C. |
| Thickness | Yield and tensile strength fall as thickness rises, so give the thickness range of your plates. |
| Welding | Preheat and consumables depend on carbon equivalent and thickness; ask for the mill’s welding recommendations. |
| Documents | EN 10204 3.1 or 3.2 mill certificate, with ultrasonic testing where specified. |
APPLICATION:
- Machine building
- Lifting equipment
- Heavy transportation
- Steel constructions
CHEMICAL COMPOSITION
| Grade | C | Si | Mn | P | S | N | B | Cr | Cu | Mo | Nb* | Ni | Ti* | V* | Zr* |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| S690 QL | 0.20 | 0.80 | 1.70 | 0.025 | 0.015 | 0.015 | 0.0050 | 1.50 | 0.50 | 0.70 | 0.06 | 2.0 | 0.05 | 0.12 | 0.15 |
Reading the chemistry: The values are maximum percentages. Elements marked * are grain-refining and micro-alloying elements.
MECHANICAL PROPERTIES
| Designation | Mechanical Properties (ambient temperature) | |||||||
|---|---|---|---|---|---|---|---|---|
| Steel Name | Steel Number | Min. Yield Strength Reh MPa | Tensile Strength Rm MPa | Min. % elongation after fracture | ||||
| Nominal thickness (mm) | Nominal thickness (mm) | |||||||
| ≥3 ≤50 | ≥50 ≤100 | ≥100 ≤150 | ≥3 ≤50 | ≥50 ≤100 | ≥100 ≤150 | |||
| S690 QL | 1.8931 | 690 | 650 | 630 | 770/940 | 760/930 | 710/900 | 14 |
Material number and strength: The material number 1.8931 belongs to S690Q; S690QL is 1.8928 and S690QL1 is 1.8988 (see the DILLIMAX 690 page). “770/940” means 770–940 MPa tensile strength, and yield is 690, 650 and 630 MPa for the three thickness ranges.
V NOTCH IMPACT TESTING
| Grade | Sample Orientation | @ 0°C | @-20°C | @-40°C | @-60°C |
|---|---|---|---|---|---|
| S690 QL | Longitudinal | 50 J | 40 J | 30 J | –– |
| Traverse | 35 J | 30 J | 27 J | –– |
Impact table: “––” means no requirement at −60 °C for this grade. “Traverse” means transverse.
Choosing a Quenched and Tempered Structural Plate
These brands are all quenched and tempered high-yield structural steels used where design strength is limited by plate weight. They are comparable in strength class but not identical: thickness range, chemistry, toughness grades and welding advice differ by mill.
| Brand | Basis | Notes from the pages |
|---|---|---|
| S690 QL (this page) | EN 10025-6 grade, 690 MPa minimum yield up to 50 mm | Impact guaranteed at −40 °C; start here if the brand is not fixed |
| DILLIMAX 690 | Dillinger brand, in B, T and E qualities (S690Q, S690QL, S690QL1) | B at −20 °C, T at −40 °C, E at −60 °C; 6–255 mm (B, T) |
| WELDOX 700 | SSAB brand, in E and F qualities | E at −40 °C, F at −60 °C; 4–160 mm (E), 4–130 mm (F) |
| NAXTRA 70 | S690QL-class quenched and tempered structural steel | Machine building, lifting equipment, heavy transport |
| SUPRALSIM 690 | Quenched and tempered, 690 N/mm² minimum yield, low sulphur and phosphorus | Weight-saving structures; forming and welding |
| MAXIL 690 | 690 MPa-class brand listed with the other high-strength steels | Ask for the datasheet |
| JFE 780 LE | JFE HITEN 780 N/mm² class, 685 MPa minimum yield | Impact at −40 °C; 5–160 mm |
Use the grade and brand approved in your design; confirm any substitution with your engineer.
Related plates in this range
Cutting, Fabrication and Welding
Champak Industries describes full and part plate/profile supply and a plasma-cutting service. Send drawings, quantities, tolerances and edge preparation for your parts. High-strength plate needs controlled preheat, interpass temperature and heat input when welding, and forming limits depend on the grade and thickness; follow the mill’s recommendations.
Testing, Inspection Documents and Traceability
| Requirement | What to identify in the order |
|---|---|
| Mill test certificate | EN 10204 3.1 showing brand and grade, heat number, chemistry and mechanical properties |
| Impact test | Charpy test temperature and minimum energy, if required |
| Ultrasonic test | Standard and acceptance class, if required |
| Traceability | Heat and plate number transferred to cut pieces |
See the company’s Quality Policy for its published policy.
Source S690 QL Plates from Champak Industries
Champak Industries’ company profile records its establishment in Mumbai in 1978 and its stockist, import and export activities. S690 QL Plates can be requested together with other plates in the High Tensile Plates range.
What Determines the Quotation?
Grade and brand, thickness, plate size, quantity, cutting, testing and packing all affect the quotation. Say whether pricing is needed per kilogram, per plate or per finished piece.
Packing, Dispatch and Export Requirements
Give the delivery address, required date and unloading constraints. For export orders, include the destination port, delivery terms and document list.
We Supply S690 QL Plates in listed cities in India
Mumbai, Lucknow, Coimbatore, Imphal, Mysore, Ratlam, Delhi, Kanpur, Darjeeling, Jalandhar, Nagpur, Solapur, Kolkata, Allahabad, Dehradun, Jammu, Nashik, Srinagar, Chennai, Ahmedabad, Faridabad, Jamshedpur, Bhadravati, Chattisgarh, Durgapur, Asansol, Hospet, Bellary, Visakhapatnam, Nellore, Surat, Bangalore, Chandigarh, Ghaziabad, Jhansi, Patna, Siliguri, Hyderabad, Stainless Steel Pipe dealers in Salem, Amritsar, Noida, Kochi (Cochin), Mangalore, Indore, Vadodra, Bhubaneswar, Bikaner, Bhavnagar, Tirupur, Ankleshwar, Warangal, Agartala, Thoothukudi, Stainless Steel Pipe suppliers in Pune, We offer fastest delivery in India including Thiruvanthapuram, Jaipur, Aizawl, Guwahati, Kozhikode, Raipur, Vishakhapatnam, Jabalpur, Bhopal, Gwalior, Ludhiana, Rajahmundry, Thane, Agra, Bhubaneshwar, Gurgaon, Madurai, Rajkot, Varanasi, Bhilai, Haridwar, Meerut, Ranchi, Ahmednagar, Akola, Amravati, Aurangabad, Baramati, Beed, Bhandara, Bhiwandi, Buldhana, Chandrapur, Chimur, Dahanu, Dhule, Dindori, Erandol, Gadchiroli, Hatkanangle, Hingoli, Ichalkaranji, Jalgaon, Jalna, Karad, Khed, Yavatmal, Kolaba, Kolhapur, Kopargaon, Latur, Malegaon, Mumbai, Nagpur, Nanded, Nandurbar, Nashik, Osmanabad, Pandharpur, Parbhani, Rajapur, Ramtek, Ratnagiri, Raver, Sangli, Satara, Shirdi, Shirur, Solapur, Thane, Wardha, Washim, Andhra Pradesh, Jammu and Kashmir, Nagaland, Uttarakhand, Haryana, Lakshadweep, Arunachal Pradesh, Jharkhand, Odisha, West Bengal, Himachal Pradesh, Assam, Karnataka, Punjab, Andaman and Nicobar Islands, Puducherry, Bihar, Kerala, Rajasthan, Chandigarh, Meghalaya, Chhattisgarh, Madhya Pradesh, Sikkim, Dadar and Nagar Haveli, Mizoram, Goa, Maharashtra, Tamil Nadu, Daman and Diu, Tripura, Gujarat, Manipur, Telangana, Delhi, Uttar Pradesh in India.
Location note: The phrases “Stainless Steel Pipe dealers in Salem” and “Stainless Steel Pipe suppliers in Pune” in the list above refer to the cities of Salem and Pune. This page does not cover stainless steel pipe.
We Supply and Export in listed Country
United States of America, Malaysia, UAE, Indonesia, Saudi Arabia, Iran, Qatar, India, China, United Kingdom, Singapore, Canada, Thailand, South Korea, Turkey, Philippines, Egypt, Germany, Italy, Japan, Russia, Vietnam, Australia, South Africa, Portugal, Morocco, Costa Rica, Kazakhstan, Netherlands, Mexico, Brazil, France, Spain, Taiwan, Nigeria, Bangladesh, Kuwait, Iraq, Ukraine, Poland, Jordan, Romania, Oman, Hong Kong, Venezuela, Colombia, Norway, Chile, Trinidad & Tobago, Greece, Czechia, Belgium, Sri Lanka, Cyprus, Angola, Myanmar (Burma), United Kingdom, Canada, South Korea, Thailand, Netherlands, Spain, Turkey, Australia, Mexico, Pakistan, Vietnam, Brazil, Philippines, France, Taiwan, Poland, South Africa, Russia, Nigeria, Kuwait, Czechia, Norway, Romania, Egypt, Oman, Sweden, Belgium, Hong Kong, Israel, Colombia, Switzerland, Denmark, Finland, Argentina, Venezuela, Peru, Ukraine, Chile, Bangladesh, Portugal, Ireland, Austria, Algeria, Greece, Iraq, New Zealand, Slovakia, Hungary, Kazakhstan, Slovenia, Lithuania, Serbia, Sri Lanka, Bahrain, Bulgaria, Morocco, Tunisia, Croatia, Jordan, Ecuador, Trinidad & Tobago, Estonia, Azerbaijan, Ghana, Lebanon, Cyprus, Dominican Republic, Latvia, Libya, Costa Rica, Cambodia, Macedonia (FYROM), Belarus, Jamaica, Palestine, Turkmenistan
S690 QL Plates: Frequently Asked Questions
01What is S690 QL Plates?
S690 QL is a quenched and tempered high-strength structural steel to EN 10025-6 with 690 MPa minimum yield strength for plate up to 50 mm thick and impact values guaranteed at −40 °C.
02What do the letters in S690QL mean?
S is structural steel, 690 is the minimum yield strength in MPa, Q is quenched and tempered, and L means impact energy is guaranteed at −40 °C (L1 is −60 °C).
03Does yield strength change with thickness?
Yes. The page lists 690 MPa up to 50 mm, 650 MPa over 50 to 100 mm and 630 MPa over 100 to 150 mm, with a tensile range that also falls with thickness.
04What impact values does the page list?
For S690 QL it lists 50 J, 40 J and 30 J longitudinal and 35 J, 30 J and 27 J transverse at 0 °C, −20 °C and −40 °C.
05Can S690 QL be welded?
Yes, with low-hydrogen consumables and the preheat and interpass temperatures the mill gives for the grade and combined thickness.
06Which certificate should I request?
An EN 10204 3.1 mill test certificate showing the brand and grade, heat number, chemistry and mechanical properties, plus impact results where you specify a test temperature.
07Can another brand replace S690 QL?
Brands of the same class are comparable, not identical. Chemistry, toughness, thickness range and processing advice differ by mill, so confirm any substitution with your engineer.
08Can S690 QL plate be cut to size?
Yes. Champak Industries lists full and part plate and profile supply and a plasma-cutting service; send drawings, quantities and tolerances with your enquiry.
09Which sizes are available?
Availability depends on the grade, mill and thickness; send the thickness, width and length you need and sizes will be confirmed at quotation.
10How do I get a price and delivery date?
Send the grade, thickness, size or cutting drawing, quantity, destination and required date through the enquiry form below, by WhatsApp or by phone.
