16mo3 Plates Steel is a pressure vessel steel that is used in applications with elevated temperatures in step with EN 10028–2. It has improved mechanical properties and better creep resistance allowing it for use as much as 500°c. This makes it best for an extensive variety of makes use of in which the plates will need to carry out at an excessive temperature continuously.
About the 500°C figure: EN 10028-2 gives 16Mo3 elevated-temperature proof strengths up to 500°C, and creep data for longer service. That is not a guaranteed maximum service temperature: the allowable temperature and stress come from your design code, load and design life.
16MO3 Plates: Purchasing Specification
| Requirement | What to specify |
|---|---|
| Grade and standard | 16Mo3 (1.5415) to EN 10028-2; state the edition. EN 10028-1 general requirements apply. |
| Delivery condition | Normally +N (normalized); +NT where the standard allows it for heavier thicknesses. |
| Published sizes | 5 mm to 250 mm thick, 2000 or 3000 mm wide, 4000, 6000, 8000 or 12000 mm long (listed below). |
| Tolerances | EN 10029 thickness-tolerance class, flatness and any tighter project limits. |
| Processing | Full plate, cut piece or profile; drawing, quantity, edge preparation and machining allowance. |
| Documents and tests | EN 10204 3.1 or 3.2, impact-test temperature, UT and any simulated PWHT. |
Dimensions, Condition and Tolerances
Specify thickness × width × length and the number of plates or pieces. For profiles, provide a dimensioned drawing with units, revision and finished-part tolerances. EN 10028-2 sets lower minimum strength for thicker plate, so confirm the properties for your thickness range before ordering heavy plate.
16mo3 Steel Applications
Typical applications for 16mo3 include a wide variety of power plant device, business exhaust, venting and flare structures and waste recycling and incineration flora. It's also valuable for equipment where components are probably to stay warm for an extended period.
In energy plant life it's far frequently utilized in boilers, super heater tubes, collector and hot steam pipes, range tubes and conduits. 16mo3 is also used in diverse sorts of heat exchanger in both the upstream and downstream oil and gas industry
One example of ways 16mo3 plates is used is in the steel making manner itself. the blast furnace requires masses of hot air to transform the iron to steel and plenty of the output air is recovered and used to reheat the enter and reduce expenses. Historically the blast furnaces are product of general carbon pressure vessel steels; however 16mo3 offers a very good alternative as it is more immune to the large thermal stresses that it undergoes on an everyday foundation. The 16mo3 is also extra proof against the corrosion fashioned with the aid of nitrates as nitrogen oxide is eliminated from the steel mix. And this aggregate of residences can boom the lifestyles expectancy of essential plant equipment and decrease downtime.
For 16mo3 warmness resistance is supplied through the 0.32% molybdenum alloying detail.
Reading the applications: “Power plant device”, “business exhaust” and “incineration flora” mean power-plant equipment, industrial exhaust and incineration plant. Superheater tubes, headers and steam pipes are tube and pipe products made to tube standards such as EN 10216-2; this page covers plate. The blast-furnace example refers to hot-blast equipment; 16Mo3 has better elevated-temperature strength than carbon steel, but it is not a corrosion-resistant alloy, so corrosion allowance still applies. EN 10028-2 sets molybdenum at 0.25–0.35%; 0.32% is a typical value.
Specify the Conditions Behind the Application
| Component or duty | Information for selection |
|---|---|
| Boiler drums and pressure vessels | Design temperature, pressure, thickness and design code (for example EN 12952 or EN 13445). |
| Heat exchanger shells | Process temperature, media, pressure and PWHT requirement. |
| Hot-air, flue and exhaust ducting | Operating temperature, thermal cycling and corrosion allowance. |
16mo3 Equivalents
It is equal to 15mo3 (DIN 17155 – Germany), 15d3 (NFA 36–205 – France), bs1501–243b (BS 1501 – UK) and ASTM 204 Gr .B. for customers requiring these grades we can provide 16mo3 from stock.
Comparable, not equal: 15Mo3 (DIN 17155), 15D3 (NF A 36-205) and BS 1501-243B are former national grades that EN 10028-2 replaced; ASTM A204 Grade B is a carbon-½Mo plate with different carbon and strength requirements. Supplying 16Mo3 against an order for one of these grades needs the purchaser’s approval, and the certificate will show EN 10028-2 16Mo3.
| Grade named in the original | Standard | Status |
|---|---|---|
| 15Mo3 | DIN 17155 (Germany) | Withdrawn; replaced by EN 10028-2 16Mo3 |
| 15D3 | NF A 36-205 (France) | Withdrawn; replaced by EN 10028-2 |
| 243B | BS 1501 (UK) | Withdrawn; replaced by EN 10028-2 |
| A204 Grade B | ASTM A204 / ASME SA204 | Current; comparable C–½Mo plate, not identical |
16mo3 Plates to be had Ex-Inventory
We shares 16mo3 metal plates – ASTM 204 b – in lengths of 4000 mm, 6000 mm, 8000 mm and 12000 mm.
Widths are either 2000mm or 3000 mm and thicknesses are from five mm to 250mm.
- Thickness5 – 250 mm
- Width2000 / 3000 mm
- Length4000 – 12000 mm
| 16Mo3 | |
|---|---|
| Tensile Strength (MPa) | 440 – 590 |
| Yield Strength (MPa) | 220 – 275 |
| Elongation in 100 – 150mm (%) | 19 |
| Elongation in 16mm (%) | 24 |
| Max Thickness (mm) | 250 |
Reading this section: “ASTM 204 b” refers to the comparable ASTM A204 Grade B; the stock plate is 16Mo3. In the table, “220 – 275” is not a yield range: EN 10028-2 gives minimum yield strengths that fall from about 275 MPa for thin plate to lower values for thick plate, and tensile strength also falls above 60 mm. Check the minimums for your thickness on the inspection document.
Why Select 16MO3 Plates?
16Mo3 adds about 0.3% molybdenum to a carbon-manganese pressure-vessel steel. The molybdenum raises strength and creep resistance at elevated temperature compared with carbon steels such as P265GH, while keeping good weldability. Where temperatures or creep demands are higher, chromium-molybdenum grades such as 13CrMo4-5 and 10CrMo9-10 are used instead.
| Grade | Nominal alloying | Typical reason to choose |
|---|---|---|
| P265GH / P295GH | Carbon-manganese | Moderate temperatures at lowest cost |
| 16Mo3 | 0.3% Mo | Higher elevated-temperature strength than carbon steel |
| 13CrMo4-5 | 1% Cr – 0.5% Mo | Higher temperatures and better oxidation resistance |
| 10CrMo9-10 | 2.25% Cr – 1% Mo | Hotter service and hydrogen duty |
These grades are not interchangeable; use the grade approved in your design. P265GH and P295GH are shown for comparison and are not listed on this site.
Cutting, Fabrication and Welding
Champak Industries describes full and part plate/profile supply and a plasma-cutting service. Send drawings, piece quantities, tolerances, edge preparation and machining allowances for your 16Mo3 requirement.
Welding
16Mo3 welds readily with matching molybdenum-alloyed consumables (Mo type to ISO 2560 / ISO 14341, or AWS E7018-A1). Thicker sections need preheat; follow the qualified WPS and EN 1011-2 guidance.
Forming and PWHT
Hot forming or heat treatment after delivery can change the +N properties; agree any re-normalizing or PWHT with the design code, and tell us the PWHT cycle if test pieces need simulated heat treatment.
Testing, Inspection Documents and Traceability
Specify the inspection document, delivery condition and cast identification when ordering. A management-system certificate is separate from a material inspection document or project approval.
| Requirement | What to identify in the order |
|---|---|
| Inspection document | EN 10204 3.1 or 3.2 showing cast analysis, delivery condition, tensile and impact results |
| Impact test | Test temperature and minimum energy, if different from the standard |
| Elevated-temperature proof stress | Verification at a stated temperature, where your code requires it |
| UT and traceability | Ultrasonic testing (for example EN 10160); cast and plate number transferred to cut pieces |
See the company’s Quality Policy for its published policy.
Source 16MO3 Plates from Champak Industries
Champak Industries’ company profile records its establishment in Mumbai in 1978 and its stockist, import and export activities. This page lists 16Mo3 plate from stock from 5 mm to 250 mm thick in 2000 mm and 3000 mm widths, which suits both thin and very heavy pressure-vessel work. It can be requested together with the other EN 10028-2 grades.
What Determines the 16Mo3 Plate Quotation?
Thickness, plate size, quantity, delivery condition, impact and ultrasonic testing, cutting, inspection and packing all affect the quotation. Include the destination, and say whether pricing is needed per kilogram, per plate or per finished piece.
Packing, Dispatch and Export Requirements
Give the delivery address, required date and unloading constraints; heavy plate may need special handling. For export orders, include the destination port, delivery terms and document list.
We Supply 16MO3 Plates in listed cities in India
Mumbai, Lucknow, Coimbatore, Imphal, Mysore, Ratlam, Delhi, Kanpur, Darjeeling, Jalandhar, Nagpur, Solapur, Kolkata, Allahabad, Dehradun, Jammu, Nashik, Srinagar, Chennai, Ahmedabad, Faridabad, Jamshedpur, Bhadravati, Chattisgarh, Durgapur, Asansol, Hospet, Bellary, Visakhapatnam, Nellore, Surat, Bangalore, Chandigarh, Ghaziabad, Jhansi, Patna, Siliguri, Hyderabad, Stainless Steel Pipe dealers in Salem, Amritsar, Noida, Kochi (Cochin), Mangalore, Indore, Vadodra, Bhubaneswar, Bikaner, Bhavnagar, Tirupur, Ankleshwar, Warangal, Agartala, Thoothukudi, Stainless Steel Pipe suppliers in Pune, We offer fastest delivery in India including Thiruvanthapuram, Jaipur, Aizawl, Guwahati, Kozhikode, Raipur, Vishakhapatnam, Jabalpur, Bhopal, Gwalior, Ludhiana, Rajahmundry, Thane, Agra, Bhubaneshwar, Gurgaon, Madurai, Rajkot, Varanasi, Bhilai, Haridwar, Meerut, Ranchi, Ahmednagar, Akola, Amravati, Aurangabad, Baramati, Beed, Bhandara, Bhiwandi, Buldhana, Chandrapur, Chimur, Dahanu, Dhule, Dindori, Erandol, Gadchiroli, Hatkanangle, Hingoli, Ichalkaranji, Jalgaon, Jalna, Karad, Khed, Yavatmal, Kolaba, Kolhapur, Kopargaon, Latur, Malegaon, Mumbai, Nagpur, Nanded, Nandurbar, Nashik, Osmanabad, Pandharpur, Parbhani, Rajapur, Ramtek, Ratnagiri, Raver, Sangli, Satara, Shirdi, Shirur, Solapur, Thane, Wardha, Washim, Andhra Pradesh, Jammu and Kashmir, Nagaland, Uttarakhand, Haryana, Lakshadweep, Arunachal Pradesh, Jharkhand, Odisha, West Bengal, Himachal Pradesh, Assam, Karnataka, Punjab, Andaman and Nicobar Islands, Puducherry, Bihar, Kerala, Rajasthan, Chandigarh, Meghalaya, Chhattisgarh, Madhya Pradesh, Sikkim, Dadar and Nagar Haveli, Mizoram, Goa, Maharashtra, Tamil Nadu, Daman and Diu, Tripura, Gujarat, Manipur, Telangana, Delhi, Uttar Pradesh in India.
Location note: The phrases “Stainless Steel Pipe dealers in Salem” and “Stainless Steel Pipe suppliers in Pune” in the list above refer to the cities of Salem and Pune. This page does not cover stainless steel pipe.
We Supply and Export in listed Country
United States of America, Malaysia, UAE, Indonesia, Saudi Arabia, Iran, Qatar, India, China, United Kingdom, Singapore, Canada, Thailand, South Korea, Turkey, Philippines, Egypt, Germany, Italy, Japan, Russia, Vietnam, Australia, South Africa, Portugal, Morocco, Costa Rica, Kazakhstan, Netherlands, Mexico, Brazil, France, Spain, Taiwan, Nigeria, Bangladesh, Kuwait, Iraq, Ukraine, Poland, Jordan, Romania, Oman, Hong Kong, Venezuela, Colombia, Norway, Chile, Trinidad & Tobago, Greece, Czechia, Belgium, Sri Lanka, Cyprus, Angola, Myanmar (Burma), United Kingdom, Canada, South Korea, Thailand, Netherlands, Spain, Turkey, Australia, Mexico, Pakistan, Vietnam, Brazil, Philippines, France, Taiwan, Poland, South Africa, Russia, Nigeria, Kuwait, Czechia, Norway, Romania, Egypt, Oman, Sweden, Belgium, Hong Kong, Israel, Colombia, Switzerland, Denmark, Finland, Argentina, Venezuela, Peru, Ukraine, Chile, Bangladesh, Portugal, Ireland, Austria, Algeria, Greece, Iraq, New Zealand, Slovakia, Hungary, Kazakhstan, Slovenia, Lithuania, Serbia, Sri Lanka, Bahrain, Bulgaria, Morocco, Tunisia, Croatia, Jordan, Ecuador, Trinidad & Tobago, Estonia, Azerbaijan, Ghana, Lebanon, Cyprus, Dominican Republic, Latvia, Libya, Costa Rica, Cambodia, Macedonia (FYROM), Belarus, Jamaica, Palestine, Turkmenistan
16MO3 Plates: Frequently Asked Questions
01What is 16Mo3 steel?
16Mo3 (1.5415) is a molybdenum alloy steel to EN 10028-2 for pressure equipment in elevated-temperature service. It contains about 0.3% molybdenum.
02Is 16Mo3 a chrome moly steel?
No. It has no chromium addition, but it is used for similar elevated-temperature duties and is grouped with the chrome moly range.
03Is 16Mo3 the same as ASTM A204 Grade B?
They are comparable molybdenum steels but not identical; the standards differ in chemistry and strength. Substitution needs the purchaser’s approval.
04Which 16Mo3 plate sizes are listed?
5 mm to 250 mm thick, 2000 or 3000 mm wide, and 4000, 6000, 8000 or 12000 mm long.
05What delivery condition is 16Mo3 supplied in?
Normally normalized (+N). EN 10028-2 also permits normalized and tempered (+NT) for heavier thicknesses; state the condition your specification requires.
06Up to what temperature can 16Mo3 be used?
EN 10028-2 gives elevated-temperature properties up to 500°C, but the allowable temperature and stress come from your design code and design life, not a single figure.
07Does the strength of 16Mo3 change with thickness?
Yes. Minimum yield and tensile strength are lower for thicker plate, so check the values for your thickness range.
08Can 16Mo3 plate be welded?
Yes, with matching molybdenum-alloyed consumables and a qualified procedure. Thick sections need preheat.
09Which inspection document should I request?
Usually EN 10204 3.1, or 3.2 where a third-party inspector must witness testing. State the impact temperature and any UT requirement.
10How do I get a price and delivery date?
Send the condition, sizes, quantity, cutting, tests, destination and required date through the enquiry form below, by WhatsApp or by phone.
